ELS61 Series

Catalog

RF TXRX MODULE CELL SMD

Part	Operating Temperature [Max]	Operating Temperature [Min]	Serial Interfaces	Data Rate	Package / Case	Memory Size	RF Family/Standard	Protocol	Voltage - Supply [Max]	Voltage - Supply [Min]	Mounting Type	Frequency	Antenna Type	Power - Output	Utilized IC / Part
Telit Cinterion ELS61-US REL.2 CI	85 °C	-40 C	ADC GPIO I2C PWM SPI USB	10.2 Mbps	Module	18 MB 31 MB	Cellular	GSM HSPA+ LTE UMTS	4.5 V	3 V	Surface Mount	1.7 GHz 1.9 GHz 2.1 GHz 700 MHz 850 MHz	Antenna Not Included
Telit Cinterion ELS61-AUS REL.1 MR NT	90 °C	-40 C	ADC GPIO I2C I2S PCM SPI UART USB	10.2 Mbps	122-LGA Module	18 MB 30 MB	Cellular	EDGE GPRS GSM HSDPA HSUPA LTE UMTS	4.5 V	3 V	Surface Mount	1.8 GHz 2.1 GHz 700 MHz 850 MHz 900 MHz	Antenna Not Included	33 dBm	Intel XMM 7160
Telit Cinterion ELS61-E2 REL.1 MR	85 °C	-40 C	ADC GPIO I2C PWM SPI USB	10.2 Mbps	Module	18 MB 31 MB	Cellular	GSM HSPA+ LTE UMTS	4.5 V	3 V	Surface Mount	1.8 GHz 2.1 GHz 700 MHz 800 MHz 900 MHz	Antenna Not Included
