A2E170 Series
Manufacturer: ebm-papst Inc.
Beta
⌘K
AC AXIAL FAN
| Part | Current Rating (Amps) | Material - Blade [custom] | Bearing Type | Operating Temperature | Operating Temperature | Approval Agency | Features | RPM | Power (Watts) | Width [x] | Fan Type | Termination | Size / Dimension | Size / Dimension [diameter] | Voltage - Rated | Ingress Protection | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | 0.23 A | Aluminum | Ball | 60 °C | 60 °C | CE EAC | Capacitor Thermal Overload Protector (TOP) | 3150 RPM | 53 W | 65 mm | Tubeaxial | 4 Wire Leads with Splice Terminals | Round | 170 mm | 230 VAC | IP44 | ||
 ebm-papst Inc. | 0.23 A | Aluminum | Ball | CCC CE EAC | Capacitor Thermal Overload Protector (TOP) | 3150 RPM | 53 W | 65 mm | Tubeaxial | 4 Wire Leads with Splice Terminals | Round | 170 mm | 230 VAC | IP44 | -25 °C | 60 °C | ||
 ebm-papst Inc. | 0.23 A | Aluminum | Ball | Capacitor Thermal Overload Protector (TOP) | 3150 RPM | 53 W | 65 mm | Tubeaxial | 4 Wire Leads with Splice Terminals | Round | 170 mm | 230 VAC | IP44 | -25 °C | 60 °C |
