BD2243G Series
Manufacturer: Rohm Semiconductor
Beta
⌘K
POWER SWITCH ICS - POWER DISTRIBUTION HI SIDE USB PWR SW
| Part | Rds On (Typ) | Input Type | Switch Type | Fault Protection | Ratio - Input:Output | Voltage - Supply (Vcc/Vdd) | Voltage - Load [Min] | Voltage - Load [Max] | Output Configuration | Number of Outputs | Interface | Mounting Type | Output Type | Supplier Device Package | Current - Output (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Features | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 89 mOhm | Inverting | USB Switch | Current Limiting (Adjustable) Over Temperature Reverse Current UVLO | 1:1 | Not Required | 2.8 V | 5.5 V | High Side | 1 | On/Off | Surface Mount | N-Channel | 6-SSOP | 1.7 A | 85 C | -40 ¯C | Load Discharge Status Flag | SOT-23-6 |
