PS-16PE Series

Catalog

CONN HEADER VERT 16POS 2.54MM

Part	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions	Number of Positions Loaded	Style	Contact Finish - Post	Overall Contact Length	Overall Contact Length	Number of Rows [custom]	Contact Type	Insulation Height [z]	Insulation Height [z]	Insulation Material	Contact Material	Contact Finish - Mating	Material Flammability Rating	Connector Type	Contact Shape	Insulation Color	Pitch - Mating	Pitch - Mating	Fastening Type	Termination	Shrouding	Contact Length - Mating	Contact Length - Mating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Length - Post [custom]	Contact Length - Post	Mounting Type	Contact Length - Post	Contact Finish Thickness - Post	Overall Contact Length	Features	Insulation Height	Insulation Height	Insulation Height
JAE Electronics PS-16PE-D4T1-M1E	3.9 µin	0.099 µm	16	All	Board to Cable/Wire	Tin	0.638 in	16.21 mm	2	Male Pin	0.681 in	17.3 mm	Polybutylene Terephthalate (PBT)	Copper Alloy	Gold	UL94 V-0	Header	Square	Black	0.1 "	2.54 mm	Latch Lock/Eject Hooks Long	Solder	Shrouded - 4 Wall	6 mm	0.236 in	0.1 in	2.54 mm	0.11 in	2.79 mm	Through Hole
JAE Electronics PS-16PE-D4T2-M1E	3.9 µin	0.099 µm	16	All	Board to Cable/Wire	Tin	0.657 in	16.7 mm	2	Male Pin	0.681 in	17.3 mm	Polybutylene Terephthalate (PBT)	Copper Alloy	Gold	UL94 V-0	Header	Square	Black	0.1 "	2.54 mm	Latch Lock/Eject Hooks Long	Solder	Shrouded - 4 Wall	6 mm	0.236 in	0.1 in	2.54 mm		3.3 mm	Through Hole	0.13 "
JAE Electronics PS-16PE-D4T1-LP1	3.9 µin	0.099 µm	16	All	Board to Cable/Wire	Gold			2	Male Pin	0.701 in	17.8 mm	Polybutylene Terephthalate (PBT)	Copper Alloy	Gold	UL94 V-0	Header	Square	Black	0.1 "	2.54 mm	Latch Lock/Eject Hooks	Solder	Shrouded - 4 Wall	6 mm	0.236 in	0.1 in	2.54 mm			Through Hole		Flash
JAE Electronics PS-16PE-D4T1-B1E	3.9 µin	0.099 µm	16	All	Board to Cable/Wire	Tin		0.461 in	2	Male Pin			Polybutylene Terephthalate (PBT)	Copper Alloy	Gold	UL94 V-0	Header	Square	Black	0.1 "	2.54 mm	Latch Holder	Solder	Shrouded - 4 Wall	6 mm	0.236 in	0.1 in	2.54 mm	0.11 in	2.79 mm	Through Hole			11.7 mm	Keying Slot	8.89 mm	0.35 in
JAE Electronics PS-16PE-S4T1-KLB1			16
JAE Electronics PS-16PE-D4LT2-M1E	3.9 µin	0.099 µm	16	All	Board to Cable/Wire	Tin			2	Male Pin	0.327 "		Polybutylene Terephthalate (PBT)	Copper Alloy	Gold	UL94 V-0	Header	Square	Black	0.1 "	2.54 mm	Latch Lock/Eject Hooks	Solder	Shrouded - 4 Wall	6 mm	0.236 in	0.1 in	2.54 mm		3.3 mm	Right Angle Through Hole	0.13 "					8.3 mm
JAE Electronics PS-16PE-D4T2-SM1E	3.9 µin	0.099 µm	16	All	Board to Cable/Wire	Tin	0.638 in	16.21 mm	2	Male Pin	0.681 in	17.3 mm	Polybutylene Terephthalate (PBT)	Copper Alloy	Gold	UL94 V-0	Header	Square	Black	0.1 "	2.54 mm	Latch Lock/Eject Hooks	Solder	Shrouded - 4 Wall	6 mm	0.236 in	0.1 in	2.54 mm		3.3 mm	Through Hole	0.13 "
JAE Electronics PS-16PE-D4LT1-SM1E	3.9 µin	0.099 µm	16	All	Board to Cable/Wire				2	Male Pin	0.327 "		Polybutylene Terephthalate (PBT)	Copper Alloy	Gold	UL94 V-0	Header	Square	Black	0.1 "	2.54 mm	Latch Lock/Eject Hooks	Solder	Shrouded - 4 Wall	6 mm	0.236 in	0.1 in	2.54 mm	0.11 in	2.79 mm	Right Angle Through Hole						8.3 mm
JAE Electronics PS-16PE-D4LT1-LP1	3.9 µin	0.099 µm	16	All	Board to Cable/Wire	Gold			2	Male Pin			Polybutylene Terephthalate (PBT)	Copper Alloy	Gold	UL94 V-0	Header	Square	Black	0.1 "	2.54 mm	Latch Lock/Eject Hooks	Solder	Shrouded - 4 Wall	6 mm	0.236 in	0.1 in	2.54 mm	0.11 in	2.79 mm	Right Angle Through Hole		Flash				9 mm	0.354 in
