357-033 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SGL FML 33POS 0.156
...
| Part | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Color | Material - Insulation | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Number of Positions | Contact Material | Contact Type | Flange Feature | Features | Card Type | Number of Positions/Bay/Row [custom] | Contact Finish | Termination | Termination Rows | Read Out | Number of Rows | Pitch [x] | Pitch [x] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole | 33 | Copper Alloy | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | Non Specified - Single Edge | 33 | Tin | Solder | 1 | Single | 1 | 0.156 in | 3.96 mm | ||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole Right Angle | 66 | Copper Alloy | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 33 | Tin | Solder | 1 | Dual | 2 | 0.156 in | 3.96 mm | |||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole Right Angle | 33 | Copper Alloy | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | Non Specified - Single Edge | 33 | Gold | Solder | 1 | Single | 1 | 0.156 in | 3.96 mm | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole | 33 | Copper Alloy | Semi Bellows | Floating Bobbin Flush Mount | Non Specified - Single Edge | 33 | Gold | Solder | 1 | Single | 1 | 0.156 in | 3.96 mm | 10 Áin | 0.25 Ám | 0.116 in | 2.95 mm | |
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole | 66 | Copper Alloy | Semi Bellows | Flush Mount Top Opening Unthreaded | Non Specified - Dual Edge | 33 | Gold | Wire Wrap | 1 | Dual | 2 | 0.156 in | 3.96 mm | 10 Áin | 0.25 Ám | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole | 33 | Copper Alloy | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | Non Specified - Single Edge | 33 | Tin | Wire Wrap | 1 | Single | 1 | 0.156 in | 3.96 mm | ||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole | 66 | Copper Alloy | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | Non Specified - Dual Edge | 33 | Gold | Solder Eyelet(s) | 1 | Dual | 2 | 0.156 in | 3.96 mm | 10 Áin | 0.25 Ám | ||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole | 33 | Copper Alloy | Semi Bellows | Flush Mount Top Opening Unthreaded | Non Specified - Single Edge | 33 | Gold | Wire Wrap | 1 | Single | 1 | 0.156 in | 3.96 mm | 10 Áin | 0.25 Ám | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole | 33 | Copper Alloy | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | Non Specified - Single Edge | 33 | Tin | Wire Wrap | 1 | Single | 1 | 0.156 in | 3.96 mm | ||||
 EDAC Inc. | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Polyester Thermoplastic | Female | -40 °C | 105 ░C | Through Hole | 33 | Copper Alloy | Semi Bellows | Flush Mount Top Opening Unthreaded | Non Specified - Single Edge | 33 | Tin | Solder | 1 | Single | 1 | 0.156 in | 3.96 mm | 0.156 in | 3.96 mm |
