SI86SQ44 Series

Catalog

6.0 KVRMS QSPI COMPATIBLE ISOLAT

Part	Inputs - Side 1/Side 2 [custom]	Number of Channels [custom]	Voltage - Supply [Min]	Voltage - Supply [Max]	Voltage - Isolation	Data Rate	Common Mode Transient Immunity (Min) [Min]	Mounting Type	Pulse Width Distortion (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Channel Type	Package / Case	Package / Case	Package / Case	Technology	Propagation Delay tpLH / tpHL (Max) [Max] [x]	Propagation Delay tpLH / tpHL (Max) [Max] [y]	Type	Supplier Device Package	Package / Case [x]	Package / Case [y]	Propagation Delay tpLH / tpHL (Max) [custom]	Propagation Delay tpLH / tpHL (Max) [custom]	Grade	Qualification
Skyworks Solutions Inc. SI86SQ44EE-IS2	4	4	2.25 V	5.5 V	6000 Vrms	150 Mbps	100 V/ns	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SOIC	7.5 mm	0.295 "	Capacitive Coupling	14 ns	14 ns	General Purpose	16-SOIC
Skyworks Solutions Inc. SI86SQ44BE-IS2R	4	4	2.25 V	5.5 V	6000 Vrms	150 Mbps	100 V/ns	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SOIC	7.5 mm	0.295 "	Capacitive Coupling	14 ns	14 ns	General Purpose	16-SOIC
Skyworks Solutions Inc. SI86SQ44EB-IUR	4	4	2.25 V	5.5 V	2500 Vrms	150 Mbps	100 V/ns	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SSOP			Capacitive Coupling	14 ns	14 ns	General Purpose	16-QSOP	0.154 in	3.9 mm
Skyworks Solutions Inc. SI86SQ44BE-AS2R	4	4	2.25 V	5.5 V	6000 Vrms	150 Mbps	150 kV/µs	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SOIC	7.5 mm	0.295 "	Capacitive Coupling			SPI	16-SOIC			42 ns	42 ns	Automotive	AEC-Q100
Skyworks Solutions Inc. SI86SQ44BE-AS2	4	4	2.25 V	5.5 V	6000 Vrms	150 Mbps	150 kV/µs	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SOIC	7.5 mm	0.295 "	Capacitive Coupling			SPI	16-SOIC			42 ns	42 ns	Automotive	AEC-Q100
Skyworks Solutions Inc. SI86SQ44BB-AU	4	4	2.25 V	5.5 V	2500 Vrms	150 Mbps	150 kV/µs	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SSOP			Capacitive Coupling			SPI	16-QSOP	0.154 in	3.9 mm	42 ns	42 ns	Automotive	AEC-Q100
Skyworks Solutions Inc. SI86SQ44EE-AS2R	4	4	2.25 V	5.5 V	6000 Vrms	150 Mbps	150 kV/µs	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SOIC	7.5 mm	0.295 "	Capacitive Coupling			SPI	16-SOIC			42 ns	42 ns	Automotive	AEC-Q100
Skyworks Solutions Inc. SI86SQ44BB-IUR	4	4	2.25 V	5.5 V	2500 Vrms	150 Mbps	100 V/ns	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SSOP			Capacitive Coupling	14 ns	14 ns	General Purpose	16-QSOP	0.154 in	3.9 mm
Skyworks Solutions Inc. SI86SQ44EB-AUR	4	4	2.25 V	5.5 V	2500 Vrms	150 Mbps	150 kV/µs	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SSOP			Capacitive Coupling			SPI	16-QSOP	0.154 in	3.9 mm	42 ns	42 ns	Automotive	AEC-Q100
Skyworks Solutions Inc. SI86SQ44EE-AS2	4	4	2.25 V	5.5 V	6000 Vrms	150 Mbps	150 kV/µs	Surface Mount	2 ns	125 °C	-40 C	2.5 ns	2.5 ns	Unidirectional	16-SOIC	7.5 mm	0.295 "	Capacitive Coupling			SPI	16-SOIC			42 ns	42 ns	Automotive	AEC-Q100
