Gt0 Series Series

Sealed Ultraminiature Toggle Switch

Manufacturer: Littelfuse/Commercial Vehicle Products

Catalog

Sealed Ultraminiature Toggle Switch

Part	Illumination	Bushing Thread	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Termination Style	Switch Function	Features	Voltage Rating - DC	Voltage Rating - AC	Actuator Material	Actuator Length [x]	Electrical Life	Circuit	Current Rating (Amps)	Actuator Type
Littelfuse/Commercial Vehicle Products GT12MCBE	Non-Illuminated	Unthreaded	Through Hole	-30 ░C	85 °C	PC Pin	On-Off	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	SPST	0.4 VA	Standard Round
Littelfuse/Commercial Vehicle Products GT12MSABE	Non-Illuminated	Unthreaded	Surface Mount Right Angle	-30 ░C	85 °C	Gull Wing	On-Off	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	SPST	0.4 VA	Standard Round
Littelfuse/Commercial Vehicle Products GT23MAVBE	Non-Illuminated	Unthreaded	Right Angle Through Hole Vertical	-30 ░C	85 °C	PC Pin	On-Off-On	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	DPDT	0.4 VA	Standard Round
Littelfuse/Commercial Vehicle Products GT12MABE	Non-Illuminated	Unthreaded	Through Hole Right Angle	-30 ░C	85 °C	PC Pin	On-Off	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	SPST	0.4 VA	Standard Round
Littelfuse/Commercial Vehicle Products GT12MV3BE	Non-Illuminated	Unthreaded	Through Hole	-30 ░C	85 °C	PC Pin	On-Off	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	SPST	0.4 VA	Standard Round
Littelfuse/Commercial Vehicle Products GT12MSCKETR	Non-Illuminated	Unthreaded	Surface Mount	-30 ░C	85 °C	Gull Wing	On-Off	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	SPST	0.4 VA	Standard Round
Littelfuse/Commercial Vehicle Products GT12MAKE	Non-Illuminated	Unthreaded	Through Hole Right Angle	-30 ░C	85 °C	PC Pin	On-Off	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	SPST	0.4 VA	Standard Round
Littelfuse/Commercial Vehicle Products GT13MABE	Non-Illuminated	Unthreaded	Through Hole Right Angle	-30 ░C	85 °C	PC Pin	On-Off-On	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	SPDT	0.4 VA	Standard Round
Littelfuse/Commercial Vehicle Products GT13MCBE	Non-Illuminated	Unthreaded	Through Hole	-30 ░C	85 °C	PC Pin	On-Off-On	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	SPDT	0.4 VA	Standard Round
Littelfuse/Commercial Vehicle Products GT13MV3BE	Non-Illuminated	Unthreaded	Through Hole	-30 ░C	85 °C	PC Pin	On-Off-On	Epoxy Sealed Terminals	20 V	20 V	Glass Filled Nylon Polyamide (PA)	3.81 mm	40000 Cycles	SPDT	0.4 VA	Standard Round

Catalog

Sealed Ultraminiature Toggle Switch

Key Features

• Sealed against solder and cleaning process contaminants

• Ultraminiature size, smallest footprint available

• High temperature materials (UL 94V-0)

Description

GT series sealed ultraminiature toggle switches from C&K are used most often in hand-held telecommunications devices or those applications that require small instrumentation. The GT series are ultraminiature switches – featuring the smallest footprint available in the industry. GT switches are built using high-temperature materials (UL 94V-0) and are sealed against solder and cleaning process contaminants – ensuring they will last when used in harsh environments.
