C3CEG-3 Series

Catalog

IDC CABLE - CKC34G/AE34M/CCE34G

Part	Contact Finish	Number of Rows [custom]	Color	Cable Termination	Connector Type	Contact Finish Thickness	Contact Finish Thickness	Number of Positions [custom]	Pitch - Cable	Pitch - Cable	Length	Length	Length	Shielding	Pitch - Connector	Pitch - Connector	Features	Length [x]	Length [x]
CW Industries C3CEG-3406M	Gold	2	Multiple Ribbon	IDC	Socket to Card Edge	0.25 Ám	10 Áin	34	0.05 in	1.27 mm	152.4 mm	0.5 '	6 "	Unshielded	0.1 in	2.54 mm	Polarizing Key
CW Industries C3CEG-3418G	Gold	2		IDC	Socket to Card Edge	0.25 Ám	10 Áin	34	0.05 in	1.27 mm				Unshielded	0.1 in	2.54 mm	Polarizing Key	457.2 mm	1.5 ft
CW Industries C3CEG-3436G	Gold	2		IDC	Socket to Card Edge	0.25 Ám	10 Áin	34	0.05 in	1.27 mm	91.44 cm	3 ft		Unshielded	0.1 in	2.54 mm	Polarizing Key
CW Industries C3CEG-3418M	Gold	2	Multiple Ribbon	IDC	Socket to Card Edge	0.25 Ám	10 Áin	34	0.05 in	1.27 mm				Unshielded	0.1 in	2.54 mm	Polarizing Key	457.2 mm	1.5 ft
CW Industries C3CEG-3406G	Gold	2		IDC	Socket to Card Edge	0.25 Ám	10 Áin	34	0.05 in	1.27 mm	152.4 mm	0.5 '	6 "	Unshielded	0.1 in	2.54 mm	Polarizing Key
