AC Fans AC Axial Fan
AC Fans AC Axial Fan
| Part | Material - Frame | Current Rating (Amps) | Material - Blade | Bearing Type | Approval Agency | RPM | Ingress Protection | Voltage - Rated | Width [y] | Power (Watts) | Static Pressure | Static Pressure | Size / Dimension | Size / Dimension [diameter] | Fan Type | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Features | Termination | Air Flow | Air Flow | Weight | Weight | Noise | Width [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | Steel | 1.55 A | Steel | Ball | CCC EAC | 3000 RPM | IP44 | 230 VAC | 104 mm | 350 W | 0.201 in H2O | 50.1 Pa | Round | 397 mm | Tubeaxial | 50 °C | -25 °C | -25 °C | 50 °C | Capacitor Thermal Overload Protection (TOP) | 4 Wire Leads | ||||||
 ebm-papst Inc. | Metal | Metal | Ball | CSA UL VDE | 230 VAC | 80 mm | 350 W | Round | 397 mm | Tubeaxial | 2 Wire Leads | 2200 CFM | 61.6 m³/min | 7 lbs | 3.2 kg | 76 dB(A) | |||||||||||
 ebm-papst Inc. | Ball | 2900 RPM | IP44 | 230 VAC | 190 W | 0.602 in H2O | 150 Pa | Round | 397 mm | Tubeaxial | 50 °C | -25 °C | -25 °C | 50 °C | Capacitor Thermal Overload Protector (TOP) | 4 Wire Leads with Splice Terminals | |||||||||||
 ebm-papst Inc. | Steel | 1.55 A | Steel | Ball | CCC CE CSA EAC UL | 3000 RPM | IP44 | 230 VAC | 350 W | 0.201 in H2O | 50 Pa | Round | 397 mm | Tubeaxial | -25 °C | 60 °C | Capacitor Thermal Overload Protector (TOP) | 4 Wire Leads with Splice Terminals | 113.5 mm | ||||||||
ebm-papst Inc. | Metal | Metal | Ball | CSA UL VDE | 115 VAC | 80 mm | 350 W | Round | 397 mm | Tubeaxial | 2 Wire Leads | 2200 CFM | 61.6 m³/min | 7 lbs | 3.2 kg | 76 dB(A) |
