FFC & FPC Connectors 1.00MM REC 04P RA SMT BOT
FFC & FPC Connectors 1.00MM REC 04P RA SMT BOT
| Part | Flat Flex Type | Pitch | Pitch | Housing Material | Cable End Type | FFC, FCB Thickness | Mounting Type | Locking Feature | Voltage Rating | Height Above Board [z] | Height Above Board [z] | Features | Contact Material | Termination | Actuator Material | Contact Finish | Material Flammability Rating | Connector/Contact Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | FPC | 1 mm | 0.039 in | Polyamide (PA46) Nylon 4/6 | Tapered | 0.3 mm | Right Angle Surface Mount | Slide Lock | 50 V | 0.118 in | 3 mm | Solder Retention Zero Insertion Force (ZIF) | Phosphor Bronze | Solder | Polyphenylene Sulfide (PPS) | Gold | UL94 V-0 | Contacts Bottom | 85 °C | -40 C | 4 |
 Molex | |||||||||||||||||||||
 Molex |
