316-039 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 78POS 0.156
| Part | Material - Insulation | Termination Rows | Read Out | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Material | Gender | Flange Feature | Card Type | Termination | Number of Positions/Bay/Row | Pitch | Pitch | Color | Mounting Type | Contact Type | Number of Positions | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | Solder | 39 | 3.96 mm | 0.156 in | Green | Panel Mount Through Hole | Cantilever | 78 | Tin | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | Flush Mount Top Opening Unthreaded | Non Specified - Dual Edge | Solder | 39 | 3.96 mm | 0.156 in | Green | Through Hole | Cantilever | 39 | Gold | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | Flush Mount Top Opening Unthreaded | Non Specified - Dual Edge | Solder | 39 | 3.96 mm | 0.156 in | Green | Through Hole | Cantilever | 39 | Gold | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | Solder Eyelet(s) | 39 | 3.96 mm | 0.156 in | Green | Panel Mount | Cantilever | 78 | Tin | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | Solder | 39 | 3.96 mm | 0.156 in | Green | Panel Mount Through Hole | Cantilever | 78 | Gold | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | Flush Mount Top Opening Unthreaded | Non Specified - Dual Edge | Solder | 39 | 3.96 mm | 0.156 in | Green | Panel Mount Through Hole | Cantilever | 78 | Tin | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | Solder | 39 | 3.96 mm | 0.156 in | Green | Panel Mount Through Hole | Cantilever | 78 | Tin | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | Solder | 39 | 3.96 mm | 0.156 in | Green | Panel Mount Through Hole | Cantilever | 78 | Tin | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | Solder | 39 | 3.96 mm | 0.156 in | Green | Panel Mount Through Hole | Cantilever | 78 | Tin | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Dual | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Female | Flush Mount Top Opening Unthreaded | Non Specified - Dual Edge | Solder Eyelet(s) | 39 | 3.96 mm | 0.156 in | Green | Panel Mount | Cantilever | 39 | Gold | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm |
