392-052 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 52POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Mounting Type | Number of Positions | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Read Out | Features | Number of Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Card Type | Gender | Pitch | Pitch | Number of Positions/Bay/Row | Operating Temperature [Min] | Operating Temperature [Max] | Color | Termination | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Board Edge Straddle Mount | 52 | Copper Alloy | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Gold | 0.25 Ám | 10 Áin | Dual | Card Extender | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Dual Edge | Female | 0.1 " | 2.54 mm | 26 | -40 C | 105 ░C | Black | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | Through Hole | 52 | Copper Alloy | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Gold | 0.25 Ám | 10 Áin | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Single Edge | Female | 0.1 " | 2.54 mm | 52 | -40 C | 105 ░C | Black | Solder | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Board Edge Straddle Mount | 52 | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | Gold | 0.25 Ám | 10 Áin | Dual | Card Extender | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Dual Edge | Female | 0.1 " | 2.54 mm | 26 | -40 C | 105 ░C | Black | Solder | ||||
 EDAC Inc. | Polyester Thermoplastic | Through Hole | 52 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 0.25 Ám | 10 Áin | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Single Edge | Female | 0.1 " | 2.54 mm | 52 | -40 C | 105 ░C | Black | Wire Wrap | 1 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | 52 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 0.25 Ám | 10 Áin | Dual | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Dual Edge | Female | 0.1 " | 2.54 mm | 26 | -40 C | 105 ░C | Black | Solder | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | 52 | Copper Alloy | Gold | 0.25 Ám | 10 Áin | Dual | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Dual Edge | Female | 0.1 " | 2.54 mm | 26 | -40 C | 105 ░C | Black | Solder | ||||||
 EDAC Inc. | Polyester Thermoplastic | Through Hole | 52 | Copper Alloy | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Gold | 0.25 Ám | 10 Áin | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Single Edge | Female | 0.1 " | 2.54 mm | 52 | -40 C | 105 ░C | Black | Wire Wrap | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Right Angle Through Hole | 52 | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 0.25 Ám | 10 Áin | Dual | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Dual Edge | Female | 0.1 " | 2.54 mm | 26 | -40 C | 105 ░C | Black | Solder Wire Wrap | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Through Hole | 52 | Copper Alloy | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Gold | 0.25 Ám | 10 Áin | Dual | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Dual Edge | Female | 0.1 " | 2.54 mm | 26 | -40 C | 105 ░C | Black | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | Right Angle Through Hole | 52 | Copper Alloy | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Gold | 0.25 Ám | 10 Áin | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | Non Specified - Single Edge | Female | 0.1 " | 2.54 mm | 52 | -40 C | 105 ░C | Black | Solder Wire Wrap | 1 | 1 |
