387-020 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 20POS 0.156
...
| Part | Mounting Type | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Type | Contact Material | Card Type | Number of Positions/Bay/Row [custom] | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Termination Rows | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Color | Number of Rows | Pitch [x] | Pitch [x] | Gender | Read Out | Termination | Features | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] | Number of Positions/Bay/Row [custom] | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Through Hole | 3.96 mm | Flush Mount Top Opening Unthreaded | 0.156 in | Cantilever | Copper Alloy | Non Specified - Dual Edge | 10 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 2 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 2 | 0.156 in | 3.96 mm | Female | Dual | Wire Wrap | ||||||
EDAC Inc. | Board Edge Straddle Mount | Cantilever | Copper Alloy | Non Specified - Dual Edge | 10 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 2 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 2 | 0.156 in | 3.96 mm | Female | Dual | Solder Eyelet(s) | Card Extender | ||||||||
 EDAC Inc. | Through Hole | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Cantilever | Copper Alloy | Non Specified - Dual Edge | 10 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 2 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 2 | 0.156 in | 3.96 mm | Female | Dual | Solder | ||||||
 EDAC Inc. | Through Hole | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | Copper Alloy | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 1 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 1 | 0.156 in | 3.96 mm | Female | Single | Wire Wrap | 20 | 20 | 20 | ||||||
EDAC Inc. | Through Hole | Cantilever | Copper Alloy | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 1 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 1 | 0.156 in | 3.96 mm | Female | Single | Wire Wrap | 20 | 20 | 20 | 3.25 mm | 0.128 in | |||||
 EDAC Inc. | Board Edge Straddle Mount | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Cantilever | Copper Alloy | Non Specified - Dual Edge | 10 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 2 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 2 | 0.156 in | 3.96 mm | Female | Dual | Solder Eyelet(s) | Card Extender | |||||
 EDAC Inc. | Through Hole Right Angle | Cantilever | Copper Alloy | Non Specified - Dual Edge | 10 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 2 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 2 | 0.156 in | 3.96 mm | Female | Dual | Wire Wrap | |||||||||
EDAC Inc. | Through Hole | 3.96 mm | Top Mount Opening Unthreaded | 0.156 in | Cantilever | Copper Alloy | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 1 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 1 | 0.156 in | 3.96 mm | Female | Single | Wire Wrap | 20 | 20 | 20 | ||||
 EDAC Inc. | Through Hole Right Angle | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Cantilever | Copper Alloy | Non Specified - Dual Edge | 10 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 2 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 2 | 0.156 in | 3.96 mm | Female | Dual | Wire Wrap | ||||||
 EDAC Inc. | Through Hole | Flush Mount M3 Threaded Insert Top Opening | Cantilever | Copper Alloy | Non Specified - Single Edge | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 20 | -40 °C | 105 ░C | 1 | Polyester Thermoplastic | 10 Áin | 0.25 Ám | Gold | Black | 1 | 0.156 in | 3.96 mm | Female | Single | Solder | 20 | 20 | 20 |
