HEADER CONNECTOR,PCB MOUNT,RECEPT,20 CONTACTS,PIN,0.079 PITCH,PC TAIL TERMINAL,M2X0.4 ROHS COMPLIANT: NO

Part	Contact Finish Thickness - Post [custom]	Contact Finish Thickness - Post [custom]	Mated Stacking Heights	Fastening Type	Material Flammability Rating	Contact Shape	Voltage Rating	Current Rating (Amps)	Features	Style	Row Spacing - Mating	Row Spacing - Mating	Insulation Color	Contact Material	Contact Type	Mounting Type	Contact Length - Post	Contact Length - Post	Number of Positions Loaded	Shrouding	Termination	Insulation Height	Insulation Height	Connector Type	Number of Rows [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Contact Finish - Mating	Insulation Material	Pitch - Mating	Pitch - Mating	Contact Finish - Post
Harwin Inc. M80-5112022	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	20	29.5 µin	0.75 µm	Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin-Lead
Harwin Inc. M80-5111642	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	16	29.5 µin	0.75 µm	Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin
Harwin Inc. M80-5115022	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	50	29.5 µin	0.75 µm	Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin-Lead
Harwin Inc. M80-5110422	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	4	29.5 µin	0.75 µm	Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin-Lead
Harwin Inc. M80-5110642	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	6	29.5 µin	0.75 µm	Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin
Harwin Inc. M80-5110605	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	6			Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin
Harwin Inc. M80-5112642	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	26	29.5 µin	0.75 µm	Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin
Harwin Inc. M80-5111822	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	18	29.5 µin	0.75 µm	Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin-Lead
Harwin Inc. M80-5110405	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	4			Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin
Harwin Inc. M80-5111222	118.1 µin	3 µm	7.3 mm 7.7 mm 9.75 mm 10.75 mm 13.35 mm 14.75 mm	Threaded	UL94 V-0	Circular	800 V	2.2 A	Keying Slot Mating Flange Mounting Flange Mounting Hardware	Board to Board Cable	2 mm	0.079 in	Black	Phosphor Bronze	Male Pin	Through Hole	4.4 mm	0.173 in	All	Shrouded - 4 Wall	Solder	5.6 mm	0.22 in	Header	2	-55 C	125 °C	12	29.5 µin	0.75 µm	Gold	Polyphenylene Sulfide (PPS) Glass Filled	0.079 "	2 mm	Tin-Lead
