NRF24 Series
Manufacturer: Nordic Semiconductor ASA
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
IC RF TXRX+MCU ISM>1GHZ 24QFN
| Part | RF Family/Standard | Frequency | Current - Transmitting (Min) | Current - Transmitting (Max) | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Memory Type | Memory Size (OTP) | Memory Size (SRAM) | Current - Receiving (Max) | Current - Receiving (Min) | Package / Case | Modulation | Data Rate (Max) | Type | Power - Output | Serial Interfaces | Sensitivity | Package Width | Package Name | Package Length | Operating Temperature (Min) | Operating Temperature (Max) | Mounting Type | GPIO Count | Current - Receiving | Protocol | Memory Size (Flash) | Current - Transmitting | Supplied Contents | For Use With/Related Products | Utilized IC / Part | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Nordic Semiconductor ASA | General ISM > 1GHz | 2.4 GHz | 6.8 mA | 11.1 mA | 1.9 V | 3.6 V | OTP SRAM | 16 kB | 1 kB | 13.3 mA | 12.4 mA | 24-VFQFN Exposed Pad | GFSK | 2 MBaud | TxRx + MCU | 0 dBm | I2C SPI UART | -94 dBm | 4 mm | 24-QFN | 4 mm | -40 °C | 85 °C | Surface Mount | 7 | ||||||||
 Nordic Semiconductor ASA | General ISM > 1GHz | 2.4 GHz | 11 mA | 15 mA | 1.9 V | 3.6 V | 32-VFQFN Exposed Pad | GFSK | 1000 kBaud | TxRx Only | 0 dBm | USART | -85 dBm | 5 mm | 32-QFN | 5 mm | -40 °C | 85 °C | Surface Mount | 17 mA | ANT™ | ||||||||||||
 Nordic Semiconductor ASA | General ISM > 1GHz | 2.4 GHz | 6.8 mA | 11.1 mA | 1.9 V | 3.6 V | Flash SRAM | 1 kB | 13.3 mA | 12.4 mA | 48-VFQFN Exposed Pad | GFSK | 2 MBaud | TxRx + MCU | 0 dBm | I2C JTAG SPI UART | -94 dBm | 7 mm | 48-QFN | 7 mm | -40 °C | 85 °C | Surface Mount | 31 | 16 kB | ||||||||
 Nordic Semiconductor ASA | General ISM > 1GHz | 2.4 GHz | 7 mA | 11.3 mA | 1.9 V | 3.6 V | 12.3 mA | 11.1 mA | 20-VFQFN Exposed Pad | GFSK | 2 MBaud | TxRx Only | 0 dBm | SPI | -85 dBm | 4 mm | 20-QFN | 4 mm | -40 °C | 85 °C | Surface Mount | ||||||||||||
 Nordic Semiconductor ASA | General ISM > 1GHz | 2.4 GHz | 6.8 mA | 11.1 mA | 1.9 V | 3.6 V | OTP SRAM | 16 kB | 1 kB | 13.3 mA | 12.4 mA | 24-VFQFN Exposed Pad | GFSK | 2 MBaud | TxRx + MCU | 0 dBm | I2C SPI UART | -94 dBm | 4 mm | 24-QFN | 4 mm | -40 °C | 85 °C | Surface Mount | 7 | ||||||||
Nordic Semiconductor ASA | General ISM > 1GHz | 2.4 GHz | 6.8 mA | 11.1 mA | 1.9 V | 3.6 V | Flash SRAM | 1 kB | 13.3 mA | 12.4 mA | 32-VFQFN Exposed Pad | GFSK | 2 MBaud | TxRx + MCU | 0 dBm | I2C JTAG SPI UART | -94 dBm | 5 mm | 32-QFN | 5 mm | -40 °C | 85 °C | Surface Mount | 15 | 16 kB | ||||||||
Nordic Semiconductor ASA | General ISM > 1GHz | 2.4 GHz | 6.8 mA | 11.1 mA | 1.9 V | 3.6 V | Flash SRAM | 1 kB | 13.3 mA | 12.4 mA | 32-VFQFN Exposed Pad | GFSK | 2 MBaud | TxRx + MCU | 0 dBm | I2C JTAG SPI UART | -94 dBm | 5 mm | 32-QFN | 5 mm | -40 °C | 85 °C | Surface Mount | 15 | 16 kB | ||||||||
Nordic Semiconductor ASA | General ISM > 1GHz | 2.4 GHz | 4 V | 5.25 V | Flash SRAM | 2 kB | 13.3 mA | 12.9 mA | 32-VFQFN Exposed Pad | GFSK | 2 MBaud | TxRx + MCU | 0 dBm | SPI UART USB | -94 dBm | 5 mm | 32-QFN | 5 mm | -40 °C | 85 °C | Surface Mount | 6 | 16 kB | 11.1 mA | |||||||||
Nordic Semiconductor ASA | General ISM > 1GHz | 2.4 GHz | 4 V | 5.25 V | Flash SRAM | 2 kB | 13.3 mA | 12.9 mA | 32-VFQFN Exposed Pad | GFSK | 2 MBaud | TxRx + MCU | 0 dBm | SPI UART USB | -94 dBm | 5 mm | 32-QFN | 5 mm | -40 °C | 85 °C | Surface Mount | 6 | 16 kB | 11.1 mA | |||||||||
 Nordic Semiconductor ASA | 2.4 GHz | Transceiver | Board(s) | nRF24L01+ | nRF24L01+ | Board |
