MAX4761 Series

Catalog

HIGH-BANDWIDTH, QUAD DPDT SWITCH

Part	Crosstalk	Number of Circuits [custom]	Charge Injection	Operating Temperature [Max]	Operating Temperature [Min]	Channel-to-Channel Matching (ΔRon)	Supplier Device Package	Mounting Type	Multiplexer/Demultiplexer Circuit	Switch Time (Ton, Toff) (Max) [custom]	Switch Time (Ton, Toff) (Max) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	On-State Resistance (Max) [Max]	-3db Bandwidth	Switch Circuit	Voltage - Supply, Single (V+) [Min]	Voltage - Supply, Single (V+) [Max]	Package / Case	Current - Leakage (IS(off)) (Max)
Analog Devices Inc./Maxim Integrated MAX4761EBX-TG104
Analog Devices Inc./Maxim Integrated MAX4761EWX+T	-95 dB	8	15 pC	85 °C	-40 °C	200 mOhm	36-UCSP (3x3)	Surface Mount	2:1	140 ns	50 ns	25 pF	25 pF	3.5 Ohm	150 MHz	SPDT	1.8 V	5.5 V	36-WFBGA CSPBGA	5 nA
Analog Devices Inc./Maxim Integrated MAX4761ETX+	-95 dB	8	15 pC	85 °C	-40 °C	200 mOhm	36-TQFN (6x6)	Surface Mount	2:1	140 ns	50 ns	25 pF	25 pF	3.5 Ohm	150 MHz	SPDT	1.8 V	5.5 V	36-WFQFN Exposed Pad	5 nA
