ECH-S Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

CAP FILM 2200PF 5% 100VDC RADIAL

Part	Operating Temperature [Max]	Operating Temperature [Min]	Capacitance	Termination	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Applications	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Voltage Rating - DC	Mounting Type	Tolerance	Dielectric Material	Package / Case	Lead Spacing	Lead Spacing	Size / Dimension [y]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Panasonic Industrial Automation Sales ECH-S1222JZ	125 °C	-40 °C	2200 pF	PC Pins	0.335 in	8.5 mm	High Frequency Switching	0.177 "	4.5 mm	0.394 "	10 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	5 mm	0.197 in
Panasonic Industrial Automation Sales ECH-S1104JZ	125 °C	-40 °C	100000 pF	PC Pins	0.598 in	15.2 mm	High Frequency Switching	0.276 in	7 mm	0.669 "	17 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	12.5 mm	0.492 in
Panasonic Industrial Automation Sales ECH-S1221JZ	125 °C	-40 °C	220 pF	PC Pins	0.295 in	7.5 mm	High Frequency Switching	0.157 in		0.335 "	8.5 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	5 mm	0.197 in	4 mm
Panasonic Industrial Automation Sales ECH-S1822JZ	125 °C	-40 °C		PC Pins			High Frequency Switching	0.177 "		0.472 in	12 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	7.5 mm	0.295 in	4.5 mm	0.354 in	9 mm
Panasonic Industrial Automation Sales ECH-S1334JZ	125 °C	-40 °C	0.33 µF	PC Pins			High Frequency Switching	0.394 in		0.807 "	20.5 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	15 mm	0.591 in	10 mm	0.764 "	19.4 mm
Panasonic Industrial Automation Sales ECH-S1472JZ	125 °C	-40 °C	4700 pF	PC Pins	0.335 in	8.5 mm	High Frequency Switching	0.197 "		0.394 "	10 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	5 mm	0.197 in	5 mm
Panasonic Industrial Automation Sales ECH-S1271JZ	125 °C	-40 °C	270 pF	PC Pins	0.295 in	7.5 mm	High Frequency Switching	0.157 in		0.335 "	8.5 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	5 mm	0.197 in	4 mm
Panasonic Industrial Automation Sales ECH-S1331JZ	125 °C	-40 °C	330 pF	PC Pins	0.295 in	7.5 mm	High Frequency Switching	0.157 in		0.335 "	8.5 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	5 mm	0.197 in	4 mm
Panasonic Industrial Automation Sales ECH-S1102JZ	125 °C	-40 °C	0.001 µF	PC Pins	0.315 in	8 mm	High Frequency Switching	0.177 "	4.5 mm	0.394 "	10 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	5 mm	0.197 in
Panasonic Industrial Automation Sales ECH-S1562JZ	125 °C	-40 °C	5600 pF	PC Pins			High Frequency Switching	0.177 "		0.472 in	12 mm	100 V	Through Hole	5 %	Polyphenylene Sulfide (PPS)	Radial	7.5 mm	0.295 in	4.5 mm	0.354 in	9 mm
