325-056 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 56POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Material | Contact Finish | Contact Type | Number of Positions | Card Thickness | Card Thickness | Gender | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Rows | Termination | Mounting Type | Color | Number of Positions/Bay/Row | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Termination Rows [custom] | Number of Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Solder | Through Hole | Green | 56 | -65 ░C | 125 °C | Single | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Solder Eyelet(s) | Through Hole | Green | 28 | -65 ░C | 125 °C | Dual | 2 | 2 | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | ||
EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Solder | Through Hole | Green | 28 | -65 ░C | 125 °C | Dual | 2 | 2 | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Wire Wrap | Through Hole | Green | 56 | -65 ░C | 125 °C | Single | 4-40 Flush Mount Threaded Insert Top Opening | ||||
EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Solder Eyelet(s) | Through Hole | Green | 56 | -65 ░C | 125 °C | Single | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Wire Wrap | Through Hole | Green | 28 | -65 ░C | 125 °C | Dual | 2 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Wire Wrap | Through Hole | Green | 28 | -65 ░C | 125 °C | Dual | 2 | 2 | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Solder Eyelet(s) | Through Hole | Green | 56 | -65 ░C | 125 °C | Single | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Solder | Through Hole | Green | 28 | -65 ░C | 125 °C | Dual | 2 | 2 | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Copper Alloy | Gold | Cantilever | 56 | 3.18 mm | 0.125 in | Female | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 1 | Solder | Through Hole | Green | 56 | -65 ░C | 125 °C | Single | 4-40 Flush Mount Threaded Insert Top Opening |
