1533P Series
Manufacturer: Belden Inc.
Beta
⌘K
CAT5E 4PR F/UTP CMP REEL
| Part | Shield Material | Shield Coverage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Features | Cable Type | Usage | Shield Type | Jacket Color | Voltage | Conductor Insulation | Jacket (Insulation) Material | Number of Conductors | Ratings | Conductor Strand | Length | Length | Conductor Material | Wire Gauge |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum Polyester | 100 % | 0.235 " | 5.97 mm | Drain Wire Flame Retardant | Multi-Pair Cat5e | Ethernet | Foil | Red | 300 VDC | Fluorinated Ethylene-Propylene (FEP) | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 8 | UL Style CMP | Solid | 304.8 m | 1000 ft | Copper Bare | 24 AWG |
 Belden Inc. | Aluminum Polyester | 100 % | 0.235 " | 5.97 mm | Drain Wire Flame Retardant | Multi-Pair Cat5e | Ethernet | Foil | Black | 300 VDC | Fluorinated Ethylene-Propylene (FEP) | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 8 | UL Style CMP | Solid | 304.8 m | 1000 ft | Copper Bare | 24 AWG |
Belden Inc. | Aluminum Polyester | 100 % | 0.235 " | 5.97 mm | Drain Wire Flame Retardant | Multi-Pair Cat5e | Ethernet | Foil | Blue | 300 VDC | Fluorinated Ethylene-Propylene (FEP) | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 8 | UL Style CMP | Solid | 304.8 m | 1000 ft | Copper Bare | 24 AWG |
Belden Inc. | Aluminum Polyester | 100 % | 0.235 " | 5.97 mm | Drain Wire Flame Retardant | Multi-Pair Cat5e | Ethernet | Foil | Gray | 300 VDC | Fluorinated Ethylene-Propylene (FEP) | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 8 | UL Style CMP | Solid | 304.8 m | 1000 ft | Copper Bare | 24 AWG |
Belden Inc. | Aluminum Polyester | 100 % | 0.235 " | 5.97 mm | Drain Wire Flame Retardant | Multi-Pair Cat5e | Ethernet | Foil | Blue | 300 VDC | Fluorinated Ethylene-Propylene (FEP) | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | 8 | UL Style CMP | Solid | 304.8 m | 1000 ft | Copper Bare | 24 AWG |
