392-032 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Color | Contact Finish Thickness | Contact Finish Thickness | Card Type | Contact Type | Termination | Pitch | Pitch | Mounting Type | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 16 | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Dual | Black | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Cantilever | Solder | 0.1 " | 2.54 mm | Through Hole | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 16 | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Dual | Black | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Cantilever | Solder | 0.1 " | 2.54 mm | Through Hole | ||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 32 | Gold | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Single | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Cantilever | Wire Wrap | 0.1 " | 2.54 mm | Through Hole | 1 | 1 | ||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 32 | Gold | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Single | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Cantilever | Solder Wire Wrap | 0.1 " | 2.54 mm | Right Angle Through Hole | 1 | 1 | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 16 | Gold | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Dual | Black | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Cantilever | Wire Wrap | 0.1 " | 2.54 mm | Through Hole | ||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 32 | Gold | Single | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Cantilever | Solder | 0.1 " | 2.54 mm | Through Hole | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 16 | Gold | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Dual | Black | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Cantilever | Wire Wrap | 0.1 " | 2.54 mm | Through Hole | ||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 32 | Gold | Single | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Cantilever | Solder Wire Wrap | 0.1 " | 2.54 mm | Right Angle Through Hole | 1 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 32 | Gold | Flush Mount M3 Threaded Insert Top Opening | Single | Black | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Cantilever | Solder Wire Wrap | 0.1 " | 2.54 mm | Right Angle Through Hole | 1 | 1 | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | -40 C | 105 ░C | 16 | Gold | Dual | Black | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Cantilever | Wire Wrap | 0.1 " | 2.54 mm | Through Hole |
