5200UP Series

Catalog

CABLE 2COND 16AWG BLUE

Part	Length	Length	Wire Gauge	Jacket (Insulation) Material	Features	Cable Type	Jacket Color	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Insulation	Usage	Voltage	Number of Conductors
Belden Inc. 5200UP D15U1000	304.8 m	1000 ft	16 AWG	Poly-Vinyl Chloride (PVC)	Rip Cord	Multi-Conductor	Blue	0.381 mm	0.015 in	65	34 AWG	Copper Bare	5.28 mm	0.208 "	Poly-Vinyl Chloride (PVC)	Commercial Audio	300 VDC	2
Belden Inc. 5200UP D151000	304.8 m	1000 ft	16 AWG	Poly-Vinyl Chloride (PVC)	Rip Cord	Multi-Conductor	Blue	0.381 mm	0.015 in	65	34 AWG	Copper Bare	5.28 mm	0.208 "	Poly-Vinyl Chloride (PVC)	Commercial Audio	300 VDC	2
Belden Inc. 5200UP 009U1000	304.8 m	1000 ft	16 AWG	Poly-Vinyl Chloride (PVC)	Rip Cord	Multi-Conductor	White	0.381 mm	0.015 in	65	34 AWG	Copper Bare	5.28 mm	0.208 "	Poly-Vinyl Chloride (PVC)	Commercial Audio	300 VDC	2
Belden Inc. 5200UP 0101000	304.8 m	1000 ft	16 AWG	Poly-Vinyl Chloride (PVC)	Rip Cord	Multi-Conductor	Black	0.381 mm	0.015 in	65	34 AWG	Copper Bare	5.28 mm	0.208 "	Poly-Vinyl Chloride (PVC)	Commercial Audio	300 VDC	2
Belden Inc. 5200UP 008U500	152.4 m	500 ft	16 AWG	Poly-Vinyl Chloride (PVC)	Rip Cord	Multi-Conductor	Gray	0.381 mm	0.015 in	65	34 AWG	Copper Bare	5.28 mm	0.208 "	Poly-Vinyl Chloride (PVC)	Commercial Audio	300 VDC	2
Belden Inc. 5200UP 008U1000	304.8 m	1000 ft	16 AWG	Poly-Vinyl Chloride (PVC)	Rip Cord	Multi-Conductor	Gray	0.381 mm	0.015 in	65	34 AWG	Copper Bare	5.28 mm	0.208 "	Poly-Vinyl Chloride (PVC)	Commercial Audio	300 VDC	2
Belden Inc. 5200UP 0091000	304.8 m	1000 ft	16 AWG	Poly-Vinyl Chloride (PVC)	Rip Cord	Multi-Conductor	White	0.381 mm	0.015 in	65	34 AWG	Copper Bare	5.28 mm	0.208 "	Poly-Vinyl Chloride (PVC)	Commercial Audio	300 VDC	2
