078119 Series

Manufacturer: Molex

Catalog

CONN FFC VERT 26POS 0.5MM SMD

Part	Termination	Housing Color	Cable End Type	Height Above Board	Height Above Board	FFC, FCB Thickness	Contact Finish	Material Flammability Rating	Housing Material	Pitch [x]	Pitch [x]	Number of Positions	Mating Cycles	Mounting Type	Connector/Contact Type	Contact Material	Flat Flex Type	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Amps)	Voltage Rating	Contact Finish Thickness	Contact Finish Thickness
Molex 0781191268	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Gold	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in	26	20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V
Molex 0781191128	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Gold	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in	12	20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V
Molex 0781191199	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Tin Bismuth	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in	19	20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V	39.4 Áin	1 Ám
Molex 0781191239	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Tin Bismuth	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in	23	20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V	39.4 Áin	1 Ám
Molex 0781191248	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Gold	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in	24	20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V
Molex 0781191258	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Gold	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in		20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V
Molex 0781191088	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Gold	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in	8	20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V
Molex 0781191189	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Tin Bismuth	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in	18	20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V	39.4 Áin	1 Ám
Molex 0781191228	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Gold	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in	22 positions	20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V
Molex 0781191209	Solder	Natural	Tapered	0.161 "	4.1 mm	0.3 mm	Tin Bismuth	UL94 V-0	Glass Filled Nylon 4/6 Polyamide (PA46)	0.5 mm	0.02 in	20	20	Surface Mount	Contacts Vertical - 1 Sided	Copper Alloy	FFC FPC	85 °C	-40 °C	0.5 A	50 V	39.4 Áin	1 Ám
