MT48LC8M32 Series

Catalog

IC DRAM 256MBIT PAR 90VFBGA

Part	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Memory Size	Memory Type	Mounting Type	Voltage - Supply [Max]	Voltage - Supply [Min]	Supplier Device Package	Memory Format	Write Cycle Time - Word, Page	Memory Interface	Memory Organization [custom]	Memory Organization [custom]	Clock Frequency	Access Time	Technology
Micron Technology Inc. MT48LC8M32LFB5-8 TR	0 °C	70 °C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	125 MHz	7 ns	SDRAM - Mobile LPSDR
Micron Technology Inc. MT48LC8M32LFF5-10 TR	0 °C	70 °C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	100 MHz	7 ns	SDRAM - Mobile LPSDR
Micron Technology Inc. MT48LC8M32LFB5-10	0 °C	70 °C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	100 MHz	7 ns	SDRAM - Mobile LPSDR
Micron Technology Inc. MT48LC8M32LFF5-10 IT	-40 ¯C	85 C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	100 MHz	7 ns	SDRAM - Mobile LPSDR
Micron Technology Inc. MT48LC8M32LFF5-8 IT	-40 ¯C	85 C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	125 MHz	7 ns	SDRAM - Mobile LPSDR
Micron Technology Inc. MT48LC8M32LFB5-8 IT TR	-40 ¯C	85 C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	125 MHz	7 ns	SDRAM - Mobile LPSDR
Micron Technology Inc. MT48LC8M32LFF5-10	0 °C	70 °C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	100 MHz	7 ns	SDRAM - Mobile LPSDR
Micron Technology Inc. MT48LC8M32LFF5-8	0 °C	70 °C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	125 MHz	7 ns	SDRAM - Mobile LPSDR
Micron Technology Inc. MT48LC8M32LFB5-10 TR	0 °C	70 °C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	100 MHz	7 ns	SDRAM - Mobile LPSDR
Micron Technology Inc. MT48LC8M32LFB5-10 IT TR	-40 ¯C	85 C	90-VFBGA	256 Gbit	Volatile	Surface Mount	3.6 V	3 V	90-VFBGA (8x13)	DRAM	15 ns	Parallel	8 M	32 bit	100 MHz	7 ns	SDRAM - Mobile LPSDR
