IR2137 Series
Manufacturer: INFINEON
Beta
⌘K
IC GATE DRVR HALF-BRIDGE 64MQFP
| Part | Input Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Driven Configuration | Supplier Device Package | Channel Type | Operating Temperature [Min] | Operating Temperature [Max] | High Side Voltage - Max (Bootstrap) [Max] | Package / Case | Gate Type | Number of Drivers | Mounting Type | Rise / Fall Time (Typ) [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | Inverting | 12.5 V | 20 V | Half-Bridge | 64-MQFP (20x14) | 3-Phase | -40 °C | 150 °C | 600 V | 64-BQFP | IGBT | 3 | Surface Mount | 25 ns 115 ns |
 INFINEON | Inverting | 12.5 V | 20 V | Half-Bridge | 68-PLCC (24.23x24.23) | 3-Phase | -40 °C | 150 °C | 600 V | 68-PLCC | IGBT | 3 | Surface Mount | 25 ns 115 ns |
