TSM250 Series

Catalog

RESETTABLE FUSE, PPTC, POLYSWITCH TS SERIES, 60 VDC, 130 MA, 260 MA, 2.4 S

Part	Approval Agency	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Type	Resistance - Initial (Ri) (Min)	Time to Trip	Resistance - 25°C (Typ)	Package / Case	Resistance - Post Trip (R1) (Max) [Max] [custom]	Current - Max [Max]	Voltage - Max [Max]	Thickness (Max) [Max]	Thickness (Max) [Max]	Current - Hold (Ih) (Max) [Max]	Current - Trip (It)	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Resistance - Post Trip (R1) (Max) [Max]
LITTELFUSE TSM250-130F-2	UL	0.337 in	8.2 mm	8.55 mm	0.323 in	Polymeric	4 Ohms	2.4 s	9 Ohms	4-SMD	15 Ohms	3 A	60 V	0.354 "	9 mm	130 mA	260 mA	Surface Mount	85 °C	-40 C
LITTELFUSE TSM250-130F-RA-2	UL	0.337 in	8.2 mm	8.55 mm	0.323 in	Polymeric	4 Ohms	2.4 s	22 Ohms	4-SMD		3 A	60 V	0.354 "	9 mm	130 mA	260 mA	Surface Mount	85 °C	-40 C	30 Ohms
