ACZ09BR1 Series
Manufacturer: Same Sky (Formerly CUI Devices)
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
ENCODER INCREM QUAD VERT PC PIN
| Part | Mounting Type | Built in Switch | Rotational Life (Cycles Min) | Pulses per Revolution | Orientation | Voltage - Supply | Encoder Type | Detent | Termination Style | Output Type | Actuator Type | Actuator Diameter |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 10 | Vertical | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | 6mm Dia Flatted End | |
 Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 20 | Right Angle | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | Knurled End | 6 mm |
 Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 20 | Right Angle | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | 6mm Dia Flatted End | |
 Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 15 | Right Angle | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | 6mm Dia Flatted End | |
 Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 20 | Vertical | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | 6mm Dia Flatted End | |
 Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 15 | Right Angle | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | Knurled End | 6 mm |
Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 15 | Right Angle | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | Knurled End | 6 mm |
Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 10 | Vertical | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | 6mm Dia Flatted End | |
Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 20 | Vertical | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | 6mm Dia Flatted End | |
 Same Sky (Formerly CUI Devices) | Panel PCB Through Hole | Yes | 30 K | 20 | Vertical | 5 VDC | Incremental | Yes | PC Pin | Quadrature (Incremental) | Knurled End | 6 mm |
