110-11 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN IC SKT DBL

Part	Current Rating (Amps)	Contact Resistance	Material Flammability Rating	Termination Post Length	Termination Post Length	Number of Positions or Pins (Grid) [x]	Number of Positions or Pins (Grid)	Number of Positions or Pins (Grid) [y]	Type	Type	Type	Pitch - Post	Pitch - Post	Contact Finish - Post	Housing Material	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Termination	Pitch - Mating	Pitch - Mating	Features	Contact Material - Mating	Contact Finish - Mating	Mounting Type	Contact Material - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions or Pins (Grid) [custom]	Number of Positions or Pins (Grid) [custom]	Type [custom]	Type [custom]	Number of Positions or Pins (Grid) [custom]
Mill-Max Manufacturing Corp. 110-11-964-41-001000	3 A	10 mOhm	UL94 V-0	0.125 in	3.18 mm	2	64	32	DIP	22.86 mm	0.9 in	0.1 in	2.54 mm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	-55 C	125 °C	10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin
Mill-Max Manufacturing Corp. 110-11-420-41-001000	3 A	10 mOhm	UL94 V-0	0.125 in	3.18 mm		20		DIP		0.4 in	0.1 in	2.54 mm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	-55 C	125 °C	10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin
Mill-Max Manufacturing Corp. 110-11-316-41-001000	3 A	10 mOhm	UL94 V-0	0.125 in	3.18 mm		16		DIP	7.62 mm	0.3 in	0.1 in	2.54 mm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	-55 C	125 °C	10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin	2	8
Mill-Max Manufacturing Corp. 110-11-632-41-001000	3 A	10 mOhm	UL94 V-0	0.125 in	3.18 mm		32		DIP			0.1 in	2.54 mm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	-55 C	125 °C	10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin			15.24 mm	0.6 in
Mill-Max Manufacturing Corp. 110-11-636-41-001000	3 A	10 mOhm	UL94 V-0	0.125 in	3.18 mm		36		DIP			0.1 in	2.54 mm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	-55 C	125 °C	10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin			15.24 mm	0.6 in
Mill-Max Manufacturing Corp. 110-11-624-41-001000				0.125 in	3.18 mm	12	24	2	DIP			0.1 in	2.54 mm	Gold	Thermoplastic			10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin			15.24 mm	0.6 in
Mill-Max Manufacturing Corp. 110-11-652-41-001000	3 A	10 mOhm	UL94 V-0	0.125 in	3.18 mm				DIP			0.1 in	2.54 mm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	-55 C	125 °C	10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin			15.24 mm	0.6 in
Mill-Max Manufacturing Corp. 110-11-432-41-001000	3 A	10 mOhm	UL94 V-0	0.125 in	3.18 mm		32		DIP		0.4 in	0.1 in	2.54 mm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	-55 C	125 °C	10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin
Mill-Max Manufacturing Corp. 110-11-650-41-001000	3 A	10 mOhm	UL94 V-0	0.125 in	3.18 mm	2		25	DIP			0.1 in	2.54 mm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	-55 C	125 °C	10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin			15.24 mm	0.6 in	50
Mill-Max Manufacturing Corp. 110-11-306-41-001000	3 A	10 mOhm	UL94 V-0	0.125 in	3.18 mm	2	6	3 positions or pins	DIP	7.62 mm	0.3 in	0.1 in	2.54 mm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	-55 C	125 °C	10 Áin	0.25 çm	Solder	0.1 "	2.54 mm	Open Frame	Beryllium Copper	Gold	Through Hole	Brass Alloy	0.25 µm	10 µin
