634-M15 Series
Manufacturer: EDAC Inc.
Beta
⌘K
634M SERIES RIGHT ANGLE D-SUB
| Part | Dielectric Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Features | Mounting Type | Termination | Contact Type | Number of Rows [custom] | Flange Feature | Contact Finish | Backset Spacing | Backset Spacing | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Connector Type | Contact Finish Thickness | Number of Positions | Material Flammability Rating | Connector Style | Current Rating (Amps) | Shell Material, Finish | Contact Finish Thickness | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Black | -55 C | 125 °C | Copper Alloy | Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | Housing/Shell (Unthreaded) | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | Flash | 15 | UL94 V-0 | D-Sub High Density | 5 A | ||||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Black | -55 C | 125 °C | Copper Alloy | Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | Housing/Shell (Unthreaded) | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | 15 | UL94 V-0 | D-Sub High Density | 5 A | Nickel Plated Steel | 0.38 µm | 15 µin | ||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Black | -55 C | 125 °C | Copper Alloy | Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | 4-40 | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | 15 | UL94 V-0 | D-Sub High Density | 5 A | 0.76 Ám | 30 Áin | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | White | -55 C | 125 °C | Copper Alloy | Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | 4-40 | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | 15 | UL94 V-0 | D-Sub High Density | 5 A | 0.38 µm | 15 µin | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | White | -55 C | 125 °C | Copper Alloy | Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | Housing/Shell | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | Flash | 15 | UL94 V-0 | D-Sub High Density | 5 A | 4-40 | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Black | -55 C | 125 °C | Copper Alloy | Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | Housing/Shell (Unthreaded) | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | 15 | UL94 V-0 | D-Sub High Density | 5 A | 0.38 µm | 15 µin | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | White | -55 C | 125 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | 4-40 | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | 15 | UL94 V-0 | D-Sub High Density | 5 A | Nickel Plated Steel | 0.38 µm | 15 µin | ||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | White | -55 C | 125 °C | Copper Alloy | Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | 4-40 | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | 15 | UL94 V-0 | D-Sub High Density | 5 A | Nickel Plated Steel | 0.76 Ám | 30 Áin | ||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | White | -55 C | 125 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | 4-40 | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | 15 | UL94 V-0 | D-Sub High Density | 5 A | 0.76 Ám | 30 Áin | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Black | -55 C | 125 °C | Copper Alloy | Board Lock Mounting Brackets Shielded | Board Edge Right Angle Through Hole | Solder | Signal | 3 | Housing/Shell | Gold | 8.89 mm | 0.35 in | (DE E) High Density | 1 | Receptacle Female Sockets | Flash | 15 | UL94 V-0 | D-Sub High Density | 5 A | Nickel Plated Steel | 4-40 |
