8442MN Series

Catalog

CABLE 2COND 22AWG BLUE

Part	Conductor Strand [custom]	Conductor Strand	Ratings	Voltage	Conductor Insulation	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Material	Jacket Color	Number of Conductors	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Jacket (Insulation) Material	Length	Length	Usage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Cable Type	Length [x]	Length [x]
Belden Inc. 8442MN 0061000	19 Strands	34 AWG	UL Style 2937	300 V	Polypropylene (PP)	-20 C	80 C	Copper Tinned	Blue	2	3.35 mm	0.132 in	22 AWG	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	Audio Control Instrumentation	0.406 mm	0.016 in	Multi-Conductor
Belden Inc. 8442MN 008100	19 Strands	34 AWG			Polypropylene (PP)	-20 C	80 C	Copper Tinned	Gray	2	3.35 mm	0.132 in	22 AWG	Poly-Vinyl Chloride (PVC)				0.406 mm	0.016 in	Multi-Conductor	30.5 m	100 ft
Belden Inc. 8442MN 006100	19 Strands	34 AWG	UL Style 2937	300 V	Polypropylene (PP)	-20 C	80 C	Copper Tinned	Blue	2	3.35 mm	0.132 in	22 AWG	Poly-Vinyl Chloride (PVC)			Audio Control Instrumentation	0.406 mm	0.016 in	Multi-Conductor	30.5 m	100 ft
Belden Inc. 8442MN 0081000	19 Strands	34 AWG	UL Style 2937	300 V	Polypropylene (PP)	-20 C	80 C	Copper Tinned	Gray	2	3.35 mm	0.132 in	22 AWG	Poly-Vinyl Chloride (PVC)	1000 ft	304.8 m	Audio Control Instrumentation	0.406 mm	0.016 in	Multi-Conductor
