TLE5009 Series

Manufacturer: INFINEON

Catalog

XENSIV™ - TLE5009A16 E2210 MAGNETIC ANGLE SENSOR WITH HIGH ACCURACY FOR AUTOMOTIVE, CONSUMER AND INDUSTRIAL

Part	Rotation Angle - Electrical, Mechanical [Max]	Package / Case	Mounting Type	Technology	Qualification	Voltage - Supply [Max]	Voltage - Supply [Min]	Output	Grade	Actuator Type	Termination Style	For Measuring	Output Signal	Operating Temperature [Max]	Operating Temperature [Min]	Supplier Device Package	Package / Case	Package / Case
INFINEON TLE5009A16E2210XUMA1	360 °	16-TSSOP	Surface Mount	Magnetoresistive	AEC-Q100	5.5 V	4.5 V	Analog Voltage	Automotive	External Magnet Not Included	Gull Wing	Angle	Cosine Sine	125 °C	-40 C	PG-TDSO-16
INFINEON TLE5009E1000FUMA1	360 °	8-SOIC	Surface Mount	Magnetoresistive	AEC-Q100	3.6 V	3 V	Analog Voltage	Automotive	External Magnet Not Included	Gull Wing	Angle	Cosine Sine	150 °C	-40 C		0.154 in	3.9 mm
INFINEON TLE5009A16DE2210XUMA1	360 °	16-TSSOP	Surface Mount	Magnetoresistive	AEC-Q100	5.5 V	4.5 V	Analog Voltage	Automotive	External Magnet Not Included	Gull Wing	Angle	Cosine Sine	125 °C	-40 C	PG-TDSO-16
INFINEON TLE5009A16E1200XUMA1	360 °	16-TSSOP	Surface Mount	Magnetoresistive	AEC-Q100	3.6 V	3 V	Analog Voltage	Automotive	External Magnet Not Included	Gull Wing	Angle	Cosine Sine	125 °C	-40 C	PG-TDSO-16
INFINEON TLE5009A16DE1200XUMA1	360 °	16-TSSOP	Surface Mount	Magnetoresistive	AEC-Q100	3.6 V	3 V	Analog Voltage	Automotive	External Magnet Not Included	Gull Wing	Angle	Cosine Sine	125 °C	-40 C	PG-TDSO-16
INFINEON TLE5009E2000FUMA1	360 °	8-SOIC	Surface Mount	Magnetoresistive	AEC-Q100	5.5 V	4.5 V	Analog Voltage	Automotive	External Magnet Not Included	Gull Wing	Angle	Cosine Sine	150 °C	-40 C		0.154 in	3.9 mm
INFINEON TLE5009A16E2200XUMA1	360 °	16-TSSOP	Surface Mount	Magnetoresistive	AEC-Q100	5.5 V	4.5 V	Analog Voltage	Automotive	External Magnet Not Included	Gull Wing	Angle	Cosine Sine	125 °C	-40 C	PG-TDSO-16
