TEM-125 Series

Catalog

.8MM TIGER EYE MICRO TERMINAL

Part	Contact Finish - Post	Shrouding	Contact Length - Mating	Contact Length - Mating	Mounting Type	Contact Type	Pitch - Mating	Pitch - Mating	Contact Finish - Mating	Insulation Height	Insulation Height	Connector Type	Contact Material	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions Loaded	Insulation Material	Insulation Color	Number of Positions	Termination	Fastening Type	Current Rating (Amps)	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Features	Number of Rows	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Shape	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Mated Stacking Heights
Samtec Inc. TEM-125-02-DH1-F-D-A	Tin	Shrouded - 4 Wall	0.116 in	2.95 mm	Surface Mount Right Angle	Male Pin	0.031 in	0.8 mm	Gold	6 mm	0.236 in	Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in	Board Guide	2	3 µin	0.076 µm	Square
Samtec Inc. TEM-125-02-07.0-H-D-K-TR	Gold	Shrouded - 4 Wall			Surface Mount	Male Pin	0.031 in	0.8 mm	Gold			Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in	Pick and Place	2	30 Áin	0.76 Ám	Square	3 µin	0.076 µm	10 mm
Samtec Inc. TEM-125-02-04.0-H-D	Gold	Shrouded - 4 Wall			Surface Mount	Male Pin	0.031 in	0.8 mm	Gold	6.6 mm	0.26 in	Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in		2	30 Áin	0.76 Ám	Square	3 µin	0.076 µm	7 mm
Samtec Inc. TEM-125-02-03.0-H-D-A-K-TR	Gold	Shrouded - 4 Wall			Surface Mount	Male Pin	0.031 in	0.8 mm	Gold	5.6 mm	0.22 in	Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in	Board Guide Pick and Place	2	30 Áin	0.76 Ám	Square	3 µin	0.076 µm	6 mm
Samtec Inc. TEM-125-02-07.0-G-D-WT	Gold	Shrouded - 4 Wall			Surface Mount	Male Pin	0.031 in	0.8 mm	Gold			Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in	Solder Retention	2	10 çin	0.25 çm	Square	3 µin	0.076 µm	10 mm
Samtec Inc. TEM-125-02-03.0-G-D-K-TR	Gold	Shrouded - 4 Wall			Surface Mount	Male Pin	0.031 in	0.8 mm	Gold	5.6 mm	0.22 in	Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in	Pick and Place	2	10 çin	0.25 çm	Square	3 µin	0.076 µm	6 mm
Samtec Inc. TEM-125-02-07.0-FG-D-WT-K	Gold	Shrouded - 4 Wall			Surface Mount	Male Pin	0.031 in	0.8 mm	Gold			Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in	Pick and Place Solder Retention	2	3 µin	0.076 µm	Square	3 µin	0.076 µm	10 mm
Samtec Inc. TEM-125-02-07.0-H-D-WT-K	Gold	Shrouded - 4 Wall			Surface Mount	Male Pin	0.031 in	0.8 mm	Gold			Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in	Pick and Place Solder Retention	2	30 Áin	0.76 Ám	Square	3 µin	0.076 µm	10 mm
Samtec Inc. TEM-125-02-03.0-FG-D-LC	Gold	Shrouded - 4 Wall			Surface Mount	Male Pin	0.031 in	0.8 mm	Gold	5.6 mm	0.22 in	Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in		2	3 µin	0.076 µm	Square	3 µin	0.076 µm	6 mm
Samtec Inc. TEM-125-02-03.0-FG-D-WT-K	Gold	Shrouded - 4 Wall			Surface Mount	Male Pin	0.031 in	0.8 mm	Gold	5.6 mm	0.22 in	Header	Phosphor Bronze	-55 °C	125 °C	All	Liquid Crystal Polymer (LCP)	Black	50	Solder	Push-Pull	2.9 A	1.6 mm	0.063 in	Pick and Place Solder Retention	2	3 µin	0.076 µm	Square	3 µin	0.076 µm	6 mm
