150 RMI Series

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED 35V 4700UF 20% AEC-Q200

Part	Lifetime	Size / Dimension Diameter	Ripple Current	Lead Spacing	Voltage - Rated	Mounting Type	Impedance	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	Capacitance	Height - Seated (Max)	Applications	Polarization	Tolerance	Ratings
Vishay Dale MAL215050472E3	10000 Hrs	0.709 in	2.508 A	0.295 in	35 V	Through Hole	18 mOhm	-55 °C	105 °C	Can Radial	4700 µF	1.673 in	Automotive	Polar	20 %	AEC-Q200
Vishay Dale MAL215056472E3	10000 Hrs	0.63 in	2.356 A	0.295 in	25 VAC	Through Hole	18 mOhm	-55 °C	105 °C	Can Radial	4700 µF	1.476 in	Automotive	Polar	20 %	AEC-Q200
Vishay Dale MAL215058101E3	4000 Hrs	0.394 in	273 mA	0.197 in	63 V	Through Hole	270 mOhm	-55 °C	105 °C	Can Radial	100 µF	0.512 in	Automotive	Polar	20 %	AEC-Q200
Vishay Dale MAL215051221E3	6000 Hrs	0.394 in	455 mA	0.197 in	50 V	Through Hole	120 mOhms	-55 °C	105 °C	Can Radial	220 µF	0.689 in	Automotive	Polar	20 %	AEC-Q200
Vishay Dale MAL215060471E3	6000 Hrs	0.394 in	767 mA	0.197 in	35 V	Through Hole	49 mOhm	-55 °C	105 °C	Can Radial	470 µF	0.866 in	Automotive	Polar	20 %	AEC-Q200
Vishay Dale MAL215031221E3	6000 Hrs	0.394 in	455 mA	0.197 in	50 V	Through Hole	120 mOhms	-55 °C	105 °C	Can Radial	220 µF	0.689 in	Automotive	Polar	20 %	AEC-Q200
Vishay Dale MAL215030222E3	10000 Hrs	0.63 in	2.196 A	0.295 in	35 V	Through Hole	19 mOhms	-55 °C	105 °C	Can Radial	2200 ĄF	1.319 in	Automotive	Polar	20 %	AEC-Q200
Vishay Dale MAL215068221E3	6000 Hrs	0.394 in	455 mA	0.197 in	63 V	Through Hole	150 mOhms	-55 °C	105 °C	Can Radial	220 µF	0.866 in	Automotive	Polar	20 %	AEC-Q200
Vishay Dale MAL215098686E3	10000 Hrs	0.63 in	1.14 A	0.295 in	63 V	Through Hole	54 mOhms	-55 °C	105 °C	Can Radial	680 µF	1.063 in	Automotive	Polar	20 %	AEC-Q200
