TS5A3357-Q1 Series

Automotive 5-V, 3:1, 1-channel analog multiplexer

Catalog

Automotive 5-V, 3:1, 1-channel analog multiplexer

Part	Package / Case [y]	Package / Case	Package / Case [y]	-3db Bandwidth	Channel-to-Channel Matching (ΔRon)	Multiplexer/Demultiplexer Circuit	Operating Temperature [Max]	Operating Temperature [Min]	Number of Circuits	Switch Time (Ton, Toff) (Max) [custom]	Switch Time (Ton, Toff) (Max) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	On-State Resistance (Max) [Max]	Current - Leakage (IS(off)) (Max) [Max]	Crosstalk	Charge Injection	Mounting Type	Switch Circuit	Voltage - Supply, Single (V+) [Min]	Voltage - Supply, Single (V+) [Max]	Current - Leakage (IS(off)) (Max)	Grade	Qualification
Texas Instruments TS5A3357DCUT	2.3 mm	8-VFSOP	0.091 in	334 MHz	100 mOhm	3:1	85 °C	-40 °C	1	3.7 ns	6.5 ns	10.5 pF	4.5 pF	15 Ohm	100 nA	-62 dB	3.4 pC	Surface Mount	SP3T	1.65 V	5.5 V
Texas Instruments TS5A3357DCUR	2.3 mm	8-VFSOP	0.091 in	334 MHz	100 mOhm	3:1	85 °C	-40 °C	1	3.7 ns	6.5 ns	10.5 pF	4.5 pF	15 Ohm	100 nA	-62 dB	3.4 pC	Surface Mount	SP3T	1.65 V	5.5 V
Texas Instruments TS5A3357QDCURQ1	2.3 mm	8-VFSOP	0.091 in	334 MHz	100 mOhm	3:1	125 °C	-40 °C	1	6.5 ns	10 ns	10.5 pF	4.5 pF	15 Ohm		-62 dB	3.4 pC	Surface Mount	SP3T	1.65 V	5.5 V	200 nA	Automotive	AEC-Q100
Texas Instruments TS5A3357DCURG4	2.3 mm	8-VFSOP	0.091 in	334 MHz	100 mOhm	3:1	85 °C	-40 °C	1	3.7 ns	6.5 ns	10.5 pF	4.5 pF	15 Ohm	100 nA	-62 dB	3.4 pC	Surface Mount	SP3T	1.65 V	5.5 V

Catalog

Automotive 5-V, 3:1, 1-channel analog multiplexer

Key Features

• Qualified for Automotive ApplicationsSpecified Break-Before-Make SwitchingLow ON-State ResistanceHigh BandwidthControl Inputs Are 5.5-V TolerantLow Charge InjectionExcellent ON-State Resistance MatchingLow Total Harmonic Distortion (THD)1.65-V to 5.5-V Single-Supply OperationLatch Up Exceeds 100 mA per JESD78B, Class IQualified for Automotive ApplicationsSpecified Break-Before-Make SwitchingLow ON-State ResistanceHigh BandwidthControl Inputs Are 5.5-V TolerantLow Charge InjectionExcellent ON-State Resistance MatchingLow Total Harmonic Distortion (THD)1.65-V to 5.5-V Single-Supply OperationLatch Up Exceeds 100 mA per JESD78B, Class I

Description

The TS5A3357 is a high-performance, single-pole triple throw (SP3T) analog switch that is designed to operate from 1.65 V to 5.5 V. The device offers a low ON-state resistance and low input/output capacitance and, thus, causes a very low signal distortion. The break-before-make feature allows transferring of a signal from one port to another, with a minimal signal distortion. This device also offers a low charge injection which makes this device suitable for high-performance audio and data acquisition systems. The TS5A3357 is a high-performance, single-pole triple throw (SP3T) analog switch that is designed to operate from 1.65 V to 5.5 V. The device offers a low ON-state resistance and low input/output capacitance and, thus, causes a very low signal distortion. The break-before-make feature allows transferring of a signal from one port to another, with a minimal signal distortion. This device also offers a low charge injection which makes this device suitable for high-performance audio and data acquisition systems.
