SMA201 Series

Catalog

0.2" SGL SMD DISPLAY - Y-GREEN

Part	Current - Test	Voltage - Forward (Vf) (Typ)	Color	Package / Case	Digit/Alpha Size	Digit/Alpha Size	Millicandela Rating	Display Type	Wavelength - Peak	Common Pin	Power Dissipation (Max) [Max]	Number of Characters	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Power Dissipation (Max)
American Opto Plus LED SMA201YG G/W	20 mA	2.1 V	Yellow-Green	10-SMD No Lead	0.2 in	5.08 mm	6 mcd	7-Segment	573 nm	Common Anode	70 mW	1	8 mm	0.283 in	7.2 mm	0.128 in	0.315 in	3.25 mm
American Opto Plus LED SMA201LE G/W	20 mA	2 V	Red	10-SMD No Lead	0.2 in	5.08 mm	12 mcd	7-Segment	632 nm	Common Anode	70 mW	1	8 mm	0.283 in	7.2 mm	0.128 in	0.315 in	3.25 mm
American Opto Plus LED SMA201LA G/W	20 mA	2 V	Amber	10-SMD No Lead	0.2 in	5.08 mm	12 mcd	7-Segment	612 nm	Common Anode	70 mW	1	8 mm	0.283 in	7.2 mm	0.128 in	0.315 in	3.25 mm
American Opto Plus LED SMA201LR G/W	20 mA	2 V	Red	10-SMD No Lead	0.2 in	5.08 mm	2 mcd	7-Segment	650 nm	Common Anode	75 mw	1	8 mm	0.283 in	7.2 mm	0.128 in	0.315 in	3.25 mm
American Opto Plus LED SMA201LB G/W	20 mA	3.2 V	Blue	10-SMD No Lead	0.2 in	5.08 mm	20 mcd	7-Segment	470 nm	Common Anode		1	8 mm	0.283 in	7.2 mm	0.128 in	0.315 in	3.25 mm	120 mW
American Opto Plus LED SMA201LE-UT GW	20 mA	2 V	Red	10-SMD No Lead	0.2 in	5.08 mm	15 mcd	7-Segment	632 nm	Common Anode	70 mW	1	3.35 mm	0.291 "	7.4 mm	0.433 in	0.132 "	11 mm
American Opto Plus LED SMA201LY G/W	20 mA	2 V	Yellow	10-SMD No Lead	0.2 in	5.08 mm	12 mcd	7-Segment	593 nm	Common Anode	70 mW	1	8 mm	0.283 in	7.2 mm	0.128 in	0.315 in	3.25 mm
