87610 Series

Catalog

CONN HEADER VERT 16POS 2.54MM

Part	Insulation Height	Insulation Height	Contact Finish - Post	Termination	Mounting Type	Contact Length - Mating	Contact Length - Mating	Contact Shape	Number of Positions Loaded	Insulation Color	Number of Rows	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Features	Connector Type	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Positions	Shrouding	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Material Flammability Rating	Style	Contact Finish - Mating	Fastening Type	Contact Type	Contact Material	Contact Length - Post [x]	Contact Length - Post [x]	Pitch - Mating	Pitch - Mating	Number of Positions
Amphenol ICC (FCI) 87610-216LF	9.57 mm	0.377 in	Tin	Solder	Through Hole	6 mm	0.236 in	Square	All	Blue	2	2 çm	78.7 çin	Keying Slot	Header	2.54 mm	0.1 in	16	Shrouded - 4 Wall	30 Áin	0.76 Ám	UL94 V-0	Board to Cable/Wire	Gold GXT™	Push-Pull	Male Pin	Phosphor Bronze	0.12 in	3.05 mm	0.1 in	2.54 mm
Amphenol ICC (FCI) 87610-250	9.57 mm	0.377 in		Solder	Through Hole	6 mm	0.236 in	Square	All	Blue	2			Keying Slot	Header	2.54 mm	0.1 in		Shrouded - 4 Wall	30 Áin	0.76 Ám	UL94 V-0	Board to Cable/Wire	Gold GXT™	Push-Pull	Male Pin	Phosphor Bronze	0.12 in	3.05 mm	0.1 in	2.54 mm	50
Amphenol ICC (FCI) 87610-220LF	9.57 mm	0.377 in	Tin	Solder	Through Hole	6 mm	0.236 in	Square	All	Blue	2	2 çm	78.7 çin	Keying Slot	Header	2.54 mm	0.1 in		Shrouded - 4 Wall	30 Áin	0.76 Ám	UL94 V-0	Board to Cable/Wire	Gold GXT™	Push-Pull	Male Pin	Phosphor Bronze	0.12 in	3.05 mm	0.1 in	2.54 mm	20
Amphenol ICC (FCI) 87610-214	9.57 mm	0.377 in		Solder	Through Hole	6 mm	0.236 in	Square	All	Black	2			Keying Slot	Header	2.54 mm	0.1 in		Shrouded - 4 Wall	30 Áin	0.76 Ám	UL94 V-0	Board to Cable/Wire	Gold GXT™	Push-Pull	Male Pin	Phosphor Bronze	0.12 in	3.05 mm	0.1 in	2.54 mm	14
Amphenol ICC (FCI) 87610-226	9.57 mm	0.377 in		Solder	Through Hole	6 mm	0.236 in	Square	All	Blue	2			Keying Slot	Header	2.54 mm	0.1 in		Shrouded - 4 Wall	30 Áin	0.76 Ám	UL94 V-0	Board to Cable/Wire	Gold GXT™	Push-Pull	Male Pin	Phosphor Bronze	0.12 in	3.05 mm	0.1 in	2.54 mm	26
