S6J32 Series

Manufacturer: INFINEON

Catalog

32-BIT 240 MHZ ARM CORTEX R5F MICROCONTROLLER AUTOMOTIVE AEC-Q100

Part	Package / Case	Connectivity	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Number of I/O	Program Memory Type	Speed	Core Size	Core Processor	Oscillator Type	Mounting Type	RAM Size	Data Converters	Operating Temperature [Min]	Operating Temperature [Max]	Peripherals	Supplier Device Package	Program Memory Size
INFINEON S6J32JEKSNSE20000	208-LQFP Exposed Pad	CANbus CSIO Ethernet I2C LINbus SPI UART/USART	1.1 V	5.5 V	120	FLASH	240 MHz	32-Bit	ARM® Cortex®-R5F	Internal	Surface Mount	2.125 M	A/D 46x12b	-40 °C	105 °C	DMA I2S LVD POR PWM WDT	208-TEQFP (28x28)
INFINEON S6J32GELSNSC20000	216-LQFP Exposed Pad	CANbus CSIO Ethernet I2C LINbus SPI UART/USART	2.7 V	5.5 V	128	FLASH	240 MHz	32-Bit 32-Bit Single-Core	ARM® Cortex®-R5F	Internal	Surface Mount	128 K	A/D 50x12b	-40 °C	105 °C	DMA I2S LVD POR PWM WDT	216-TEQFP (24x24)	4.0625 MB
INFINEON S6J32HELTNSC2D000	216-LQFP Exposed Pad	CANbus CSIO Ethernet I2C LINbus SPI UART/USART	1.1 V	5.5 V	128	FLASH	240 MHz	32-Bit	ARM® Cortex®-R5F	Internal	Surface Mount	2.125 M	A/D 50x12b	-40 °C	105 °C	DMA I2S LVD POR PWM WDT	216-TEQFP (24x24)
INFINEON S6J32JELSNSC20000	216-LQFP Exposed Pad	CANbus CSIO Ethernet I2C LINbus SPI UART/USART	1.1 V	5.5 V	128	FLASH	240 MHz	32-Bit	ARM® Cortex®-R5F	Internal	Surface Mount	2.125 M	A/D 50x12b	-40 °C	105 °C	DMA I2S LVD POR PWM WDT	216-TEQFP (24x24)
INFINEON S6J32BAKSESE2000A	208-LQFP Exposed Pad	CANbus CSIO Ethernet I2C LINbus SPI UART/USART	1.15 V	5.5 V	120	FLASH	240 MHz	32-Bit 32-Bit Single-Core	ARM® Cortex®-R5F	Internal	Surface Mount	512 K	A/D 50x12b	-40 °C	105 °C	DMA I2S LVD POR PWM WDT	208-TQFP (28x28)	2.112 MB
