VLBU Series

Catalog

INDUCTOR KITS & ACCESSORIES WOUND FERRITE POWER INDUCTOR SAMPLE KIT

Part	Style	Inductance Range [Min]	Inductance Range [Max]	Shielding	Packages Included	Material - Core	Mounting Type	Quantity	Quantity	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Inductance	DC Resistance (DCR)	Package / Case	Inductance Frequency - Test	Operating Temperature [Max]	Operating Temperature [Min]	Type	Tolerance	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Current - Saturation (Isat)	Current Rating (Amps)
TDK Corporation VLBU-2-KIT	Wirewound	70 nH	400 nH	Unshielded	Non-Standard SMD	Ferrite	Surface Mount	80 Pieces	16 Values
TDK Corporation VLBU9664100LT-R09L				Unshielded		Ferrite	Surface Mount			10 mm	0.394 in	90 nH	0.138 mOhm	Nonstandard	100 kHz	125 °C	-40 C	Drum Core Wirewound	15 %
TDK Corporation VLBU6565100T-R22L				Unshielded		Ferrite	Surface Mount			10 mm	0.394 in	220 nH	0.18 mOhm	Nonstandard	100 kHz	125 °C	-40 C	Drum Core Wirewound	15 %	0.256 in	6.5 mm	6.5 mm	0.256 "	33 A	70 A
