SRR4011 Series

Catalog

INDUCTOR POWER SHIELDED WIREWOUND 33UH 30% 100KHZ 15Q-FACTOR FERRITE 0.55A 0.86OHM DCR T/R

Part	Current - Saturation (Isat)	Inductance	Type	Package / Case	Tolerance	Current Rating (Amps)	Height - Seated (Max) [Max] [z]	Height - Seated (Max)	Q @ Freq	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Frequency - Self Resonant	Shielding	Mounting Type	Inductance Frequency - Test	Operating Temperature [Max]	Operating Temperature [Min]	DC Resistance (DCR) [Max]	Material - Core	Q @ Freq [custom]	Q @ Freq [custom]	Q @ Freq [custom]	DC Resistance (DCR)
Bourns Inc. SRR4011-330YL	470 mA	33 µH	Drum Core Wirewound	Nonstandard	30 %	0.55 A	0.051 in	1.3 mm	2.52 MHz 15	4.8 mm	4.8 mm	0.189 in	0.189 "	20 MHz	Shielded	Surface Mount	100 kHz	125 °C	-40 C	860 mOhm	Ferrite
Bourns Inc. SRR4011-6R2YL	1 A	6.2 µH	Drum Core Wirewound	Nonstandard	30 %	1.2 A	0.051 in	1.3 mm	7 7.96 MHz	4.8 mm	4.8 mm	0.189 in	0.189 "	51 MHz	Shielded	Surface Mount	100 kHz	125 °C	-40 C	195 mOhm	Ferrite
Bourns Inc. SRR4011-151YL	220 mA	150 µH	Drum Core Wirewound	Nonstandard	30 %	0.25 A	0.051 in	1.3 mm		4.8 mm	4.8 mm	0.189 in	0.189 "	8 MHz	Shielded	Surface Mount	100 kHz	125 °C	-40 C	3.8 Ohm	Ferrite	39	796 kHz
Bourns Inc. SRR4011-101YL	270 mA	100 µH	Drum Core Wirewound	Nonstandard	30 %	0.31 A	0.051 in	1.3 mm	18 796 kHz	4.8 mm	4.8 mm	0.189 in	0.189 "	11 MHz	Shielded	Surface Mount	100 kHz	125 °C	-40 C	2.4 Ohm	Ferrite
Bourns Inc. SRR4011-150YL	700 mA	15 µH	Drum Core Wirewound	Nonstandard	30 %	900 mA	0.051 in	1.3 mm	2.52 MHz 11	4.8 mm	4.8 mm	0.189 in	0.189 "	33 MHz	Shielded	Surface Mount	100 kHz	125 °C	-40 C	400 mOhm	Ferrite
Bourns Inc. SRR4011-470YL	400 mA	47 µH	Drum Core Wirewound	Nonstandard	30 %	480 mA	0.051 in	1.3 mm		4.8 mm	4.8 mm	0.189 in	0.189 "	18 MHz	Shielded	Surface Mount	100 kHz	125 °C	-40 C	1.25 Ohm	Ferrite	10		2.52 MHz
Bourns Inc. SRR4011-1R5YL	2.1 A	1.5 µH	Drum Core Wirewound	Nonstandard	30 %	2.3 A	0.051 in	1.3 mm	7.96 MHz 11	4.8 mm	4.8 mm	0.189 in	0.189 "	121 MHz	Shielded	Surface Mount	100 kHz	125 °C	-40 C		Ferrite				56 mOhm
