346-064 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 64POS 0.125
...
| Part | Card Type | Gender | Number of Positions | Material - Insulation | Operating Temperature [Min] | Operating Temperature [Max] | Pitch [x] | Pitch [x] | Mounting Type | Contact Finish | Contact Material | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Color | Read Out | Number of Positions/Bay/Row [custom] | Termination Rows | Number of Rows | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Termination | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Through Hole | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | 0.116 in | Floating Bobbin Flush Mount | 2.95 mm | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | |
 EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Through Hole Right Angle | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | 0.116 in | Floating Bobbin Top Mount Opening | 2.95 mm | Solder Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | |
EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Through Hole Right Angle | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | 4-40 Threaded Insert Top Mount Opening | Solder Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | |||
 EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Board Edge Straddle Mount | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | 4-40 Threaded Insert Top Mount Opening | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | |||
 EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Through Hole | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | ||||
 EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Board Edge Straddle Mount | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | M3 Threaded Insert Top Mount Opening | Solder Eyelet(s) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Card Extender | ||
 EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Through Hole | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Wire Wrap | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Card Guides | ||
 EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Through Hole | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | 0.116 in | Floating Bobbin Top Mount Opening | 2.95 mm | Solder Eyelet(s) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | |
 EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Through Hole | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Solder | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | |
 EDAC Inc. | Non Specified - Dual Edge | Female | 64 | Polyester Thermoplastic | -40 °C | 105 ░C | 0.125 in | 3.18 mm | Board Edge Straddle Mount | Gold | Copper Alloy | Cantilever | 10 Áin | 0.25 Ám | Green | Dual | 32 | 2 | 2 | 0.156 in | Flush Mount Top Opening Unthreaded | 3.96 mm | Solder Eyelet(s) | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Card Extender |
