ISK057N04 Series
Manufacturer: INFINEON
Beta
⌘K
OPTIMOS™ 6 POWER MOSFET 40 V IN SMALLEST FORM FACTOR PQFN 2X2 PACKAGE
| Part | Drive Voltage (Max Rds On, Min Rds On) | Mounting Type | Current - Continuous Drain (Id) @ 25°C | Vgs(th) (Max) @ Id | Supplier Device Package | Gate Charge (Qg) (Max) @ Vgs [Max] | Input Capacitance (Ciss) (Max) @ Vds [Max] | Vgs (Max) | Technology | Rds On (Max) @ Id, Vgs | FET Type | Drain to Source Voltage (Vdss) | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Power Dissipation (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 INFINEON | 4.5 V 10 V | Surface Mount | 64 A | 2.3 V | PG-VSON-6-1 | 12 nC | 870 pF | 20 V | MOSFET (Metal Oxide) | 5.75 mOhm | N-Channel | 40 V | 6-PowerVDFN | 155 °C | -55 °C | 2.1 W 39.1 W |
