+5 Volt Electronic Fuse
Key Features
• 60 mΩ MaxRDS(on)
• Integrated Reverse Current Protection
• Adjustable Output Current Limit Protection with Thermal Shutdown
• IEC61000−4−2 Level 4 ESD Protection for Vbusup to ±18 kV
• Fast Response Overvoltage Clamp Circuit with Selectable Level
• Internal Undervoltage Lockout Circuit
• Digital Enable with Separate FLAG for Fault Identification
• Integrated Current Monitoring
• Both Latching and Auto−Retry Options Available
• NIV Prefix for Automotive and Other Applications RequiringUnique Site and Control Change Requirements; AEC−Q100Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHSCompliant
Description
AI
The NIS6351 is a cost effective, resettable fuse which can greatlyenhance the reliability of a USB application from both catastrophicand shutdown failures.It is designed to buffer the load device from excessive input voltagewhich can damage sensitive circuits and to protect the input sidecircuitry from reverse currents. It includes an overvoltage clampcircuit that limits the output voltage during transients but does not shutthe unit down, thereby allowing the load circuit to continue itsoperation.
