614N Series

Catalog

DC FANS DC TUBEAXIAL FAN, 60X60X25MM, 24VDC, 12.4CFM, 0.9W, 16DBA, 2500RPM, SINTEC

Part	Material - Blade	Lifetime @ Temp.	Air Flow	Air Flow	Material - Frame	Voltage Range [Min]	Voltage Range [Max]	Termination	Noise	Fan Type	Approval Agency	Bearing Type	Voltage - Rated	Size / Dimension [z]	Size / Dimension [x]	Operating Temperature [Min]	Operating Temperature [Max]	RPM	Weight [custom]	Weight [custom]	Width [y]	Power (Watts)	Current Rating (Amps)	Static Pressure	Static Pressure	Weight	Weight	Features	Ingress Protection
ebm-papst Inc. 614NL	Polyamide (PA) Nylon Fiberglass Reinforced	80000 Hrs	0.347 m³/min	12.4 CFM	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	18 VDC	28 V	2 Wire Leads	16 dB	Tubeaxial	CE CSA UL VDE	Ball	24 VDC	60 mm	60 mm	-20 ░C	70 °C	2500 RPM	65.77 g	0.145 lb	25.4 mm	0.9 W
ebm-papst Inc. 614NGH	Polyamide (PA) Nylon Fiberglass Reinforced	70000 Hrs	0.708 m³/min	25.3 CFM	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	18 VDC	26 VDC	2 Wire Leads	41 dB	Tubeaxial	CE CSA EAC UL VDE	Sintec	24 VDC	60 mm	60 mm	-20 ░C	70 °C	5600 RPM			25.4 mm		0.103 A	0.363 in H2O	90.5 Pa	0.146 lb	66.22 g	Auto Restart Locked Rotor Protection
ebm-papst Inc. 614NGHH	Polyamide (PA) Nylon Fiberglass Reinforced		0.924 mł/min	33 CFM	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	18 VDC	26 VDC	2 Wire Leads	43 dB	Tubeaxial	CE CSA UL VDE	Sintec	24 VDC	60 mm	60 mm						25.4 mm	3.8 W				0.19 lb	86.18 g		IP20
ebm-papst Inc. 614N/2HH-169	Polyamide (PA) Nylon Fiberglass Reinforced	40 °C 60000 Hrs	0.89 m³/min	31.8 CFM	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	18 VDC	26 VDC	3 Wire Leads	41 dB	Tubeaxial	CE CSA EAC UL VDE	Ball	24 VDC	60 mm	60 mm	-20 ░C	70 °C	6850 RPM			25.4 mm	3 W	0.125 Amps	0.538 in H2O	134 Pa	0.146 lb	66.22 g	Auto Restart Locked Rotor Protection Speed Sensor (Tach)
ebm-papst Inc. 614NML	Polyamide (PA) Nylon Fiberglass Reinforced	80000 Hrs	0.412 mł/min	14.7 CFM	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	18 VDC	28 V	2 Wire Leads	19 dB(A)	Tubeaxial	CE CSA UL VDE	Ball	24 VDC	60 mm	60 mm	-20 ░C	70 °C	3000 RPM	65.77 g	0.145 lb	25.4 mm
ebm-papst Inc. 614NHHU-286	Polyamide (PA) Nylon Fiberglass Reinforced		0.924 mł/min	33 CFM	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	18 VDC	26 VDC	2 Wire Leads	41 dB	Tubeaxial	UL	Ball	24 VDC	60 mm	60 mm	-20 ░C	70 °C	6850 RPM			25.4 mm	2.9 W				0.146 lb	66.22 g		IP68 - Dust Tight Waterproof
ebm-papst Inc. 614NH	Polyamide (PA) Nylon Fiberglass Reinforced	70000 Hrs	0.759 m³/min	27.1 CFM	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	18 VDC	26 VDC	2 Wire Leads	37 dB	Tubeaxial	CE CSA UL VDE	Ball	24 VDC	60 mm	60 mm	-20 ░C	70 °C	5600 RPM	65.77 g	0.145 lb	25.4 mm	2.1 W
ebm-papst Inc. 614NHHR-137	Polyamide (PA) Nylon Fiberglass Reinforced		0.924 mł/min	33 CFM	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	18 VDC	26 VDC		41 dB	Tubeaxial		Ball	24 VDC	60 mm	60 mm	-20 ░C	70 °C	6850 RPM			25.4 mm	2.9 W				0.146 lb	66.22 g
