845-106 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FML 106POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Pitch | Pitch | Mounting Type | Number of Positions/Bay/Row | Contact Type | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Color | Card Type | Gender | Read Out | Termination | Number of Rows [custom] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Through Hole | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Wire Wrap | 2 | Gold | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | 125 °C | -40 C | Copper Alloy | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Through Hole | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Solder | 2 | Gold | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 125 °C | -40 C | Copper Alloy | 0.128 " | 3.25 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Board Edge Straddle Mount | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Solder | 2 | Gold | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 125 °C | -40 C | Copper Alloy | 0.128 " | 3.25 mm | Card Extender |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Through Hole | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Solder | 2 | Gold | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 125 °C | -40 C | Copper Alloy | 0.116 " | 2.95 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Through Hole | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Solder | 2 | Gold | 0.25 Ám | 10 Áin | 125 °C | -40 C | Copper Alloy | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Through Hole | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Solder Eyelet(s) | 2 | Gold | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | 125 °C | -40 C | Copper Alloy | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Right Angle Through Hole | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Solder | 2 | Gold | 0.25 Ám | 10 Áin | 125 °C | -40 C | Copper Alloy | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Through Hole | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Solder Eyelet(s) | 2 | Gold | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 125 °C | -40 C | Copper Alloy | 0.156 " | 3.96 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Through Hole | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Solder | 2 | Gold | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | 125 °C | -40 C | Copper Alloy | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Through Hole | 53 | Cantilever | 106 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Female | Dual | Solder | 2 | Gold | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 125 °C | -40 C | Copper Alloy | 0.116 " | 2.95 mm |
