03K722 Series
Manufacturer: Rosenberger
Beta
⌘K
3.50MM VERTICAL JACK PCB 26.5GHZ
| Part | Body Material | Operating Temperature [Min] | Operating Temperature [Max] | Center Contact Plating | Dielectric Material | Mating Cycles | Voltage Rating | Mounting Type | Frequency - Max [Max] | Housing Color | Center Contact Material | Connector Type | Impedance | Fastening Type | Mounting Feature | Shield Termination | Connector Style | Contact Termination | Number of Ports |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rosenberger | Stainless Steel | 0 °C | 85 °C | Gold | Polytetrafluoroethylene (PTFE) | 500 | 335 V | Panel Mount | 26.5 GHz | Silver | Beryllium Copper | Female Socket Jack | 50 Ohms | Threaded | Flange | Screw | 3.5mm | Compression | 1 |
