842-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 7POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Type | Color | Read Out | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Termination | Contact Material | Number of Positions | Mounting Type | Gender |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Wire Wrap | Copper Alloy | 7 | Through Hole | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Wire Wrap | Copper Alloy | 7 | Through Hole | Female | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Copper Alloy | 7 | Through Hole | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder Eyelet(s) | Copper Alloy | 7 | Through Hole | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Copper Alloy | 7 | Right Angle Through Hole | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder Eyelet(s) | Copper Alloy | 7 | Through Hole | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Copper Alloy | 7 | Through Hole | Female | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Copper Alloy | 7 | Through Hole | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Wire Wrap | Copper Alloy | 7 | Through Hole | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Cantilever | Green | Single | Non Specified - Single Edge | 125 °C | -40 C | 7 | 1 | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Copper Alloy | 7 | Through Hole | Female |
