842-038 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 38POS 0.100
| Part | Material - Insulation | Termination Rows | Color | Contact Finish Thickness | Contact Finish Thickness | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Mounting Type | Pitch | Pitch | Read Out | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Gender | Number of Rows | Number of Positions/Bay/Row [custom] | Card Type | Contact Material | Contact Finish | Termination Rows [custom] | Number of Positions/Bay/Row | Number of Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | 0.25 Ám | 10 Áin | Wire Wrap | 125 °C | -40 C | 38 | Through Hole | 0.1 " | 2.54 mm | Single | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | 38 | Non Specified - Single Edge | Copper Alloy | Gold | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | 0.25 Ám | 10 Áin | Solder | 125 °C | -40 C | 38 | Through Hole | 0.1 " | 2.54 mm | Dual | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Copper Alloy | Gold | 2 | 19 | 2 | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | 0.25 Ám | 10 Áin | Wire Wrap | 125 °C | -40 C | 38 | Through Hole | 0.1 " | 2.54 mm | Dual | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Copper Alloy | Gold | 2 | 19 | 2 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | 0.25 Ám | 10 Áin | Wire Wrap | 125 °C | -40 C | 38 | Through Hole | 0.1 " | 2.54 mm | Dual | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Copper Alloy | Gold | 2 | 19 | 2 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | 0.25 Ám | 10 Áin | Solder Eyelet(s) | 125 °C | -40 C | 38 | Through Hole | 0.1 " | 2.54 mm | Single | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | 38 | Non Specified - Single Edge | Copper Alloy | Gold | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | 0.25 Ám | 10 Áin | Solder | 125 °C | -40 C | 38 | Through Hole | 0.1 " | 2.54 mm | Single | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | 38 | Non Specified - Single Edge | Copper Alloy | Gold | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | 0.25 Ám | 10 Áin | Solder | 125 °C | -40 C | 38 | Right Angle Through Hole | 0.1 " | 2.54 mm | Dual | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Copper Alloy | Gold | 2 | 19 | 2 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | 0.25 Ám | 10 Áin | Wire Wrap | 125 °C | -40 C | 38 | Through Hole | 0.1 " | 2.54 mm | Dual | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Copper Alloy | Gold | 2 | 19 | 2 | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | 0.25 Ám | 10 Áin | Solder | 125 °C | -40 C | 38 | Through Hole | 0.1 " | 2.54 mm | Dual | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Non Specified - Dual Edge | Copper Alloy | Gold | 2 | 19 | 2 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Green | 0.25 Ám | 10 Áin | Wire Wrap | 125 °C | -40 C | 38 | Through Hole | 0.1 " | 2.54 mm | Single | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 1 | 38 | Non Specified - Single Edge | Copper Alloy | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm |
