9047-9513 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMA / STRAIGHT PLUG MALE PASSIVA
| Part | Mating Cycles | Center Contact Plating | Dielectric Material | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Body Material | Mounting Feature | Contact Termination | Number of Ports | Fastening Type | Housing Color | Connector Type | Frequency - Max [Max] | Connector Style | Shield Termination | Impedance | Mounting Type | Center Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | 500 | Gold | Polytetrafluoroethylene (PTFE) | 335 V | -65 ░C | 250 °C | Stainless Steel | Flange | Compression | 1 | Threaded | Silver | Plug Male Pin | 26 GHz | SMA | Screw | 50 Ohms | Panel Mount | Beryllium Copper |
