845-056 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 56POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Contact Type | Pitch | Pitch | Features | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Card Type | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Color | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Contact Finish | Mounting Type | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Cantilever | 0.1 " | 2.54 mm | Card Extender | Female | 125 °C | -40 C | 28 | Solder | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Dual | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Board Edge Straddle Mount | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Cantilever | 0.1 " | 2.54 mm | Card Extender | Female | 125 °C | -40 C | 28 | Solder | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Dual | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Board Edge Straddle Mount | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 28 | Wire Wrap | Flush Mount M3 Threaded Insert Top Opening | Dual | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Through Hole | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Cantilever | 0.1 " | 2.54 mm | Card Extender | Female | 125 °C | -40 C | 28 | Solder | M3 Threaded Insert Top Mount Opening | Dual | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Board Edge Straddle Mount | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 28 | Solder | Dual | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Through Hole | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 28 | Solder | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Dual | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Through Hole | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 56 | Wire Wrap | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Single | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Through Hole | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 56 | Solder | 4-40 Threaded Insert Top Mount Opening | Single | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Through Hole | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 28 | Wire Wrap | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Dual | Non Specified - Dual Edge | 2 | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Through Hole | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Cantilever | 0.1 " | 2.54 mm | Female | 125 °C | -40 C | 56 | Wire Wrap | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Single | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 56 | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Gold | Through Hole | 1 | 1 |
