345-082 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 82POS 0.100
...
| Part | Contact Material | Number of Rows | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Number of Positions | Gender | Contact Type | Material - Insulation | Contact Finish | Color | Contact Finish Thickness | Contact Finish Thickness | Termination Rows | Flange Feature | Mounting Type | Pitch [x] | Pitch [x] | Features | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Card Type | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | 2 | Solder | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Board Edge Straddle Mount | 2.54 mm | 0.1 in | Card Extender | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | ||||
 EDAC Inc. | Copper Alloy | 2 | Solder | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | Flush Mount Top Opening Unthreaded | Through Hole Right Angle | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | 3.96 mm | 0.156 in | |||
 EDAC Inc. | Copper Alloy | 2 | Solder Eyelet(s) | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | Side Mount Opening Unthreaded | Through Hole | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | 3.25 mm | 0.128 in | |||
 EDAC Inc. | Copper Alloy | 2 | Wire Wrap | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | 4-40 Threaded Insert Top Mount Opening | Through Hole Right Angle | 2.54 mm | 0.1 in | Card Guides | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | ||||
 EDAC Inc. | Copper Alloy | 2 | Solder | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | Board Edge Straddle Mount | 2.54 mm | 0.1 in | Card Extender | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | |||||
 EDAC Inc. | Copper Alloy | 2 | Wire Wrap | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | 4-40 Threaded Insert Top Mount Opening | Through Hole | 2.54 mm | 0.1 in | Card Guides | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | ||||
 EDAC Inc. | Copper Alloy | 2 | Wire Wrap | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole | 2.54 mm | 0.1 in | Card Guides | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | ||||
 EDAC Inc. | Copper Alloy | 2 | Solder | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | 4-40 Threaded Insert Top Mount Opening | Through Hole | 2.54 mm | 0.1 in | Card Guides | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | ||||
 EDAC Inc. | Copper Alloy | 2 | Solder | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | 4-40 Threaded Insert Top Mount Opening | Through Hole | 2.54 mm | 0.1 in | Card Guides | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge | ||||
 EDAC Inc. | Copper Alloy | 2 | Solder | -40 °C | 105 ░C | Dual | 82 | Female | Cantilever | Polyester Thermoplastic | Gold | Green | 10 Áin | 0.25 Ám | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Through Hole Right Angle | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Non Specified - Dual Edge |
