4614-0 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN RECEPT PIN .025-.037" .124"

Part	Operating Temperature [Min]	Operating Temperature [Max]	Board Thickness [Max]	Board Thickness [Max]	Board Thickness [Min]	Board Thickness [Min]	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Accepts Pin Diameter [Min]	Accepts Pin Diameter [Max]	Accepts Pin Diameter [Max]	Accepts Pin Diameter [Min]	Contact Finish Thickness	Contact Finish Thickness	Flange Diameter [diameter]	Flange Diameter [diameter]	Contact Material	Contact Finish	Length - Overall	Length - Overall	Socket Depth [z]	Socket Depth [z]	Termination	Pin Hole Diameter [diameter]	Pin Hole Diameter [diameter]	Tail Type	Accepts Square Pin Size	Accepts Square Pin Size
Mill-Max Manufacturing Corp. 4614-0-31-01-47-14-04-0	-55 C	125 °C	2.54 mm	0.1 in	1.52 mm	0.06 in	1.02 mm	0.04 in	0.64 mm	0.037 in	0.94 mm	0.025 in	0.25 Ám	10 Áin	0.072 "	1.83 mm	Beryllium Copper	Gold	0.378 "	9.6 mm	0.24 in	6.1 mm	Press-Fit	0.051 in	1.3 mm	No Tail	0.025 in	0.64 mm
Mill-Max Manufacturing Corp. 4614-0-31-15-47-14-04-0	-55 C	125 °C					1.02 mm	0.04 in	0.64 mm	0.037 in	0.94 mm	0.025 in	0.25 Ám	10 Áin	0.072 "	1.83 mm	Beryllium Copper	Gold	0.378 "	9.6 mm	0.24 in	6.1 mm	Press-Fit	0.051 in	1.3 mm	No Tail	0.025 in	0.64 mm
Mill-Max Manufacturing Corp. 4614-0-31-80-47-80-04-0	-55 C	125 °C					1.02 mm	0.04 in	0.64 mm	0.037 in	0.94 mm	0.025 in	5.08 Ám	200 Áin	0.072 "	1.83 mm	Beryllium Copper	Tin	0.378 "	9.6 mm	0.24 in	6.1 mm	Press-Fit	0.051 in	1.3 mm	No Tail	0.025 in	0.64 mm
Mill-Max Manufacturing Corp. 4614-0-31-01-47-27-04-0	-55 C	125 °C	2.54 mm	0.1 in	1.52 mm	0.06 in	1.02 mm	0.04 in	0.64 mm	0.037 in	0.94 mm	0.025 in	0.76 Ám	30 Áin	0.072 "	1.83 mm	Beryllium Copper	Gold	0.378 "	9.6 mm	0.24 in	6.1 mm	Press-Fit	0.051 in	1.3 mm	No Tail	0.025 in	0.64 mm
